Name: 10G 24 Port Poe Switch L3 Managed Ethernet Fiber Switch 400W 4*10G Fiber Ports+24*RJ45 POE Ports
Brand: Shenzhen Olycom Technology Co., Ltd.
SKU: OM288-PSE-GW
Price: 57.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Product Name: 10G 24 Port Managed Poe Switch

Fiber Port: 4*10g SFP

Bandwidth: 128Gbps

OEM: Accept

Product Dimensions: 440*205*44mm

Basic Infomation

Place of Origin: Guangdong, China

Brand Name: Olycom

Certification: CE RoHS FCC

Model Number: OM288-PSE-GW

Payment & Shipping Terms

Packaging Details: 1pc in a box

Delivery Time: 3~5 working days

Payment Terms: T/T,PayPal

Supply Ability: 5000pcs/month

Gallery

10G 24 Port Poe Switch L3 Managed Ethernet Fiber Switch 400W 4*10G Fiber Ports+24*RJ45 POE Ports

Product Description

10G 24 Port Poe Switch L3 Managed Ethernet Fiber Switch

400W 4*10G Fiber Ports+24*RJ45 POE Ports

Key Features of 10G 24 port POE Switch

Compatible with IEEE 802.1d,IEEE 802.1w,IEEE 802.1s,IEEE 802.1p,IEEE 802.3,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z, IEEE 802.3ab,IEEE 802.3ae standard;
L3 Management,support DHCP Server, QoS, ACL control, support SNMP V1/V2/V3, IGMP Snooping v1/v2；
Support Spanning Tree Protocol STP/RSTP/MSTP (ERPS), Support loop detection and self-healing, support remote loopback monitoring and control (802.3ah OAM);
Support multiple VLAN divisions, mac VLAN, protocol VLAN, private VLAN;
Support IP address + MAC address + VLAN + port binding, support DHCP Snooping, support IP source and DAI protection;
Support IPV4/IPV6,RIP v1/v2,OSPF v2
Compatible with IEEE802.3at (30W) and IEEE802.3af (15.4w) power supply standards
Support PoE management, PoE watchdog
Surge Protection: General 6KV, Differential 2KV(level B), ESD 8KV air, 6KV contact(level C)

Specification of L3 Managed Ethernet Fiber Switch

I/O Interface
Power	AC100-240V/50-60Hz
Ethernet	2410/100/1000Mbps POE Port 410G SFP+ Port 1RJ45 Console Port 1USB Port
Performance
Capacity	128Gbps
Packet Forwaring Rate	95.23Mpps
DDR SDRAM	128MByte
Flash Memory	16MByte
Packet Buffer Memory	12Mbit
MAC Address	16K
Jumbo Frame	10Kbytes
VLANs	VLAN range 1-4094, with a maximum active VLAN of 4K
Standard
Network Protocol	IEEE 802.3: Ethernet MAC Protocol IEEE 802.3i: 10BASE-T Ethernet IEEE 802.3u: 100BASE-TX Fast Ethernet IEEE 802.3ab: 1000BASE-T Gigabit Ethernet IEEE 802.3z: 1000BASE-X Gigabit Ethernet (optical fiber) IEEE 802.3ae: 10G Ethernet(optical fiber) IEEE 802.3az: Energy-efficient Ethernet IEEE 802.3ad: Standard method of performing link aggregation IEEE 802.3x: flow control IEEE 802.1ab: LLDP/LLDP-MED(Link Layer Discovery Protocol) IEEE 802.1p: LAN Layer 2 Qos/Cos protocol (multicast filtering function) related to traffic priority IEEE 802.1q: VLAN Bridge Operation IEEE 802.1x: Client/Server Access Control and Authentication Protocol IEEE 802.1d: STP IEEE 802.1s: MSTP IEEE 802.1w: RSTP
PoE Protocol	IEEE802.3af(15.4W) IEEE802.3at (30W)
Industry Standard	EMS:EN61000-4-2(ESD) EN61000-4-5(Surge)
Network Medium	10Base-T: Cat3, 4, 5 or above UTP/STP(≤100m) 100Base-TX: Cat5 or above UTP/STP(≤100m) 1000Base-TX: Cat5 or above UTP/STP(≤100m) Multi-mode Fiber: 50/125, 62.5/125, 100/140um Single-mode Fiber: 8/125,8.7/125,9/125,10/125um
Certification
Safety Certificate	CE,FCC,RoHS
Environment
Working Environment	Working Temperature: -10~50°C Storage Temperature: -40~70°C Working Humidity :10%~90%,non-condensing Storage Temperature:5%~95%,non-condensing
Function Indication
PWR (Power Indicator)	Lighting:Powered Un-Light:No Power
SYS (System Indicator)	Flashing: System startup Lighting: System Running
PoE (PoE Indicator)	Lighting:PoE on Un-Light:PoE off
ACT(Data light)	Flashing: Data transmission Not lit: No data transmission
Physical Specification
Structure Size	Product Dimensions: 44028044mm Packing Dimensions: 50036585mm Product N.W: 4.03KG Product G.W: 5.15KG
Packing Info	Carton Dimensions: 520445385mm Packing quantity: 5 sets Packing weight: 26.75KG
Power Voltage	Input voltage: AC100-240V/50-60Hz Power supply: 52V 7.5A 12V4A
Power Consumption	Product Consumption:maximum 33W PoE Budget:maximum 390W
Package List	Ethernet switch 1 set, Instruction manual 1 pcs, Certificate1 pcs, Power cord 1 pcs Serial cable 1 pcs, Brackets 1 pair

Dimension

10G 24 Port Poe Switch L3 Managed Ethernet Fiber Switch 400W 4*10G Fiber Ports+24*RJ45 POE Ports 0

FAQ:

1. What is MoQ?

1 Pc/Pair.

For many models, we have stock, it is easy to send samples for your testing.

2. Can I have a discount?

Yes and it is usually based on quantity and after sample testing.

3. What is your warranty period?

For commercial models like fiber Ethernet media converter or fiber optic PoE switch, it is 1 year.

For industrial grade products, it is 3 years.

We do lifetime technical support if the models are from Olycom company.

4. Can I have my own packing box?

Yes, the standard packing box does have not have Chinese letters or logo.

Its fine to customize your own version like putting your logo, model name or slogans on it.

5. What is your payment terms?

In most cases we do T/T wire transfer and full amount should be collected before shipment.

For sample orders, we receive PayPal payment for shorter processing time.

Sometimes Alipay or WeChat payment is fine, it depends on the cases.
