Gigabit xPON PoE ONU | EPON GPON Optical Network Unit for IP Surveillance and Fiber Access Networks

Gigabit xPON PoE ONU | EPON GPON Optical Network Unit

for IP Surveillance and Fiber Access Networks


Key Features of Gigabit PoE ONU

•  1 x 10/100/1000/2500M PON port
•  1 x 10/100/1000Mbps LAN  port
•  Support PoE af/at,
•  Support two access modes: Ethernet Passive Optical Network (EPON) and Gigabit Passive Optical Network (GPON)
•  A store-and-forward switching mechanism
•  Built-in power supply, support 100-240VAC wide voltage input
•  Compatible with main OLTs, highly compatible and stable in function

Specification

Application

Application

1. IP Video Surveillance System

OM-ON100P provides fiber-based network access and PoE power supply for IP cameras through xPON technology.

Suitable for:

• Security camera systems
• Building surveillance
• Parking monitoring
• Video intercom systems

The device supports IEEE 802.3af/at PoE output for powering compatible Ethernet devices.

2. FTTx Fiber Access Network

With dual-mode EPON and GPON support, OM-ON100P provides flexible fiber access solutions for different network infrastructures.

Applications:

• Fiber-to-the-home networks
• Enterprise fiber access
• Commercial broadband networks

It complies with IEEE 802.3ah and ITU-T G.984 standards.

3. Commercial Building Network

The built-in AC power supply design simplifies installation without requiring an external power adapter.

Applications:

• Office buildings
• Hotels
• Shopping centers
• Retail stores

4. Smart Campus Network

Provides stable fiber connectivity and PoE power for network terminals in campus environments.

Applications:

• School surveillance systems
• Enterprise campuses
• Smart building networks

5. ISP Fiber Access Network

Compatible with mainstream OLT equipment and suitable for subscriber-side ONU deployment in PON networks.

FAQ:

Q1: What is OM-ON100P?

OM-ON100P is a Gigabit single-port xPON PoE ONU integrating fiber access and PoE Ethernet output.

It supports:

• EPON
• GPON
• Gigabit Ethernet
• PoE power supply

Q2: Does it support both EPON and GPON?

Yes. OM-ON100P supports dual-mode EPON and GPON access for flexible network deployment.

Q3: Can it power IP cameras?

Yes. It supports IEEE 802.3af/at PoE output and can provide power and network connectivity for compatible IP cameras.

Q4: Does it require an external power adapter?

No. OM-ON100P has a built-in power supply and supports 100-240VAC input.

Q5: Is it compatible with different OLT brands?

Yes. It is compatible with mainstream OLT equipment for stable PON network deployment.

Q6: What makes it different from a standard ONU?

Compared with standard ONU devices, OM-ON100P integrates PoE power output and Gigabit Ethernet access, making it suitable for IP cameras and powered Ethernet terminals.
