RoHS CE 6 UTP Port rugged Industrial Managed Ethernet Switch IP40 Protection Grade

1pc
MOQ
Negotiable
Price
RoHS CE 6 UTP Port rugged Industrial Managed Ethernet Switch IP40 Protection Grade
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Industrial Managed Switch
SFP Port: 4
UTP Port: 6
Protection Grade: IP40
Poruct Weight: 0.75Kg
Product Size: 15.8 X 11.5 X 6cm
High Light:

6 UTP Port Industrial Managed Ethernet Switch

,

RoHS CE Industrial Managed Ethernet Switch

,

RoHS CE rugged ethernet switch

Basic Infomation
Place of Origin: Shenzhen, China
Brand Name: OLYCOM
Certification: CE, ROHS
Model Number: IM-FS460GW
Payment & Shipping Terms
Packaging Details: 1pc in box
Delivery Time: 3-5 workdays
Payment Terms: T/T, Western Union, L/C, D/A, D/P, MoneyGram
Supply Ability: 600pcs per month
Product Description

Industrial Managed Switch 4 SFP Fiber + 6 UTP IP40 Protection Grade With CE RoHS



Introduction



IM-FS460GW series is the 10/100/1000Mbps Industrial Managed Switch, operating temperature-40 ℃ to + 85℃, support wide voltage dual power input, meet IP40 protection degree and EMC industrial grade requirements, support many managed functions, include RSTP IGMP, VLAN, Qos, IPV6, Loop protection, ERPS and so on. The SFP fiber ports support dual fiber, Bidi SFP module. The distance can reach 120KM at most.



Key Features



Port

4 x 10/100/1000Mbps Auto-sensing TX RJ45 ports

6 x 1000Mbps SFP fiber ports

1 x console port

Managed Function

STP, RSTP, MSTP, ITU-T G.8032 Ethernet Protection Ring(EPR)

Qos, transport classification Qos, Cos, bandwidth control (input/output direction), storm suppression ,differentiated services

IEEE802.1q VLAN,VLAN port ,based Mac VLAN,IP subnet VLAN, Protocol VLAN,VLAN convert, MVR

Dynamic IEEE802.3ad LACP link aggregation, static link aggregation

IGMP/MLD snooping V1/V2/V3, IGMP filtrating/ modulating, IGMP searching

IGMP agent report, MLD snooping

Based on port and Mac IEEE802.1X, RADIUS, ACL, TACACS+,HTTP/HTTPS, SSL/SSH v2

Cisco® like CLI, Web management, SNMP v1/v2c/v3, Telnet

Software upgrade via TFTP and HTTP, firmware redundancy prevents upgrade failing

DHCP client/Relay/Snooping/Snooping option 82/Relay option 82

RMON, MIB II, mirror image, event log, DNS, NTP/SNTP, IEEE802.1ab LLDP

IPV6 Telnet server /ICMP v6, SNMP, HTTP, SSH/SSL, NTP/SNTP,TFTP, QoS, ACL

Mounted Way Din-rail
Power Supply Dual power supply
Working Tem -40°~ 85°C



Spectification



  1. Product Name: Industrial Managed Switch (4F+6UTP)
  2. Model No.: IM-FS460GW
  3. Port: 4 x 1000Mpbs SFP ports, 6 x 10/100/1000M UTP RJ45, 1 x console port
  4. Standard: IEEE 802.3, IEEE802.3U, IEEE802.3ab, IEEE802.3z, IEEE802.1d STP, IEEE802.1w RSTP,   IEEE802.1s MSTP, ITU-T G.8023 EPR/Y.1344, IEEE802.1Q, IEEE802.1X, IEEE802.3ad, IEEE802.3x, IEEE802.3af, IEEE802.3at, IEEE802.1ad, IEEE802.1p, IEEE802.1ab, IEEE802.3az
  5. VLAND ID: 4096
  6. Jumbo Frame: 9.6KB
  7. MAC Address Table Size: 8K
  8. Transmission Mode: storage and forward
  9. System Bandwidth: 48Gbps (non-traffic jam)
  10. Network Media: 10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m), 100/1000BASE-TX: CAT5 or above shielded twisted pair(≤100m), SFP port,transmission distance: 20Km,40Km,60Km,80Km,100Km
  11. LEDs: Power, network, fiber
  12. Power supply: Input voltage:DC 9-36V, Non-polar power input :support
  13. Working Temperature: -40°~ 85°C
  14. Working Humidity: 5%~95%,non-condensing
  15. Safety Class: IP40
  16. Mounted Way: Din-rail
  17. Replacement within 1year; 5 years repairing



Application
