Olycom 8 Port Industrial CCTV PoE Switch
1. Key Features
Gigabit PoE for Industrial Edge Devices
Six auto-sensing 10/100/1000Mbps RJ45 ports support IEEE 802.3af/at, delivering up to 30W per port with a total PoE budget of 180W, enabling direct power supply for IP cameras, wireless APs, and PoE-enabled industrial terminals.
Dual Gigabit Fiber Uplinks
Two 1000Mbps SFP slots support multimode and single-mode fiber modules, extending network transmission from hundreds of meters to over 100 km, ideal for distributed and noise-sensitive industrial environments.
Industrial-Grade Reliability & Protection
Designed for harsh conditions, the switch supports -40°C to +75°C operation, features 6kV Ethernet surge protection, and complies with industrial EMC, vibration, shock, and rail traffic standards.
Stable Non-Blocking Switching Performance
A store-and-forward switching architecture with 16Gbps system bandwidth ensures smooth, congestion-free forwarding of video, data, and control traffic.
Intelligent PoE Detection & Safety
Automatically detects PoE-powered devices to prevent damage to non-PoE equipment, ensuring safe and reliable power delivery.
Flexible Power & Installation Options
Powered by 48V DC input, with support for DIN-rail and wall mounting, allowing easy deployment in control cabinets, roadside enclosures, and outdoor boxes.
Fanless, Maintenance-Free Design
Natural cooling design eliminates fan failure risks and reduces maintenance requirements, enabling silent, long-term operation.
2. Technical Data
|
Product Name
|
10/100/1000Mbps Industrial PoE Fiber Switch(2F+6TP)
|
|
Model No.
|
IM-FP266GE
|
|
Port
|
2x1000M SFP Fiber
SM: 1310nm/1550nm, 20Km; 1490nm/1550nm, 40~120Km
MM: 1310nm, 2Km; 850nm, 500-meter
6x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing)
1x6-PIN Power Terminal Block
|
|
Protocol
|
IEEE 802.3(10Base-T)
IEEE 802.3u(100Base-TX)
IEEE 802.3ab(1000Base-TX)
IEEE 802.3af 15.4W(PoE)
IEEE 802.3at 30W(PoE+)
|
|
Switching Features
|
Transmission mode: storage and forward
Forwarding delay: <10us
System bandwidth: 18Gbps (non-traffic jam)
Forwarding rate: 11.904Mmps
MAC: 4K
Packet buffer size: 1.75Mb
|
|
Network Media
|
10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)
100/1000BASE-TX: CAT5 or above shielded twisted pair(≤100m)
|
|
LEDs
|
Power, Fiber, Network, PoE
PWR: Power
Fiber: FX1, FX2
On: transmission is normal
Off: transmission is NOT normal(faulty optical module or disconnected)
Copper orange: PoE indicator
On:PoE is working
Off:PoE is not working or this is Non-PoE device
Copper green: Speed indicator
On:transmission speed is 1000Mbps
Blinking: in transmission
Off:Disconnected or working speed is 10/100Mbps
|
|
Power Consumption
|
Full loading without PoE≤5W
|
|
Power Supply
|
PoE power supply input voltage: 48V (max 52V)
Single PoE power supply output power: 30W (port 1~6)
Total budget: 180W
PoE output voltage: 48V
Reverse connection: support
|
|
PoE Wiring
|
1/2 (V+), 3/6 (V-)
|
|
Environment
|
Working temperature: -40°C～75°C
Storage temperature: -40°C～85°C
Working humidity: 10%～90%, non-condensing
Storage humidity: 10%～95%, non-condensing
|
|
Industry Standards
|
ESD: IEC61000-4-2, ±15KV air, ±6KV contact
EFT: IEC61000-4-4, General ±6KV
Surge: IEC61000-4-5, Differential ±2KV, Common±6KV
|
|
Certification
|
CE-EMC: EN 55032:2015+AC: 2016+A1:2020+A11: 2020
EN 55035:2017+A11: 2020/EN IEC 61000-3-2:2019/A1: 2021
EN 61000-3-3: 2013/A2: 2021/AC:2022
CE-LVD: EN IEC 62368-1: 2020+A11:2020
FCC: 47 CFR FCC Part 15 Subpart B(Class B) ANSI C63.4: 2014
|
|
Mechanical information
|
Shell: Corrugated metal shell, IP40 grade level
Dimension: 158*115*60mm
Mounting method: Din-rail/Wall mounting
Weight: 0.75Kg/0.9Kg(Net/Gross)
|
|
Warranty
|
3 years, lifetime technical support
|
3. Overview
The Olycom IM-FP266GE is an industrial-grade Gigabit PoE fiber switch designed for environments that demand high reliability, long-distance fiber connectivity, and stable PoE power delivery.
With 6 Gigabit PoE Ethernet ports and 2 Gigabit SFP fiber uplinks, it provides a flexible network architecture for powering and connecting IP cameras, wireless access points, and industrial Ethernet devices across harsh outdoor and industrial sites.
Built with a rugged IP40 corrugated metal enclosure, wide operating temperature range from -40°C to +75°C, and industrial-level EMC protection, the IM-FP266GE ensures continuous, stable operation in automation systems, transportation networks, and mission-critical infrastructure.
4. Application
IP Surveillance & Security Systems
Ideal for powering and connecting industrial and outdoor IP cameras in smart cities, factories, campuses, and transportation hubs.
Industrial Automation Networks
Reliable Ethernet and PoE connectivity for PLCs, sensors, controllers, and field devices in manufacturing and process control systems.
Transportation & Traffic Control
Suitable for roadside cabinets, rail systems, and traffic monitoring networks requiring rugged PoE and fiber connectivity.
Energy & Utility Infrastructure
Supports substations, wind farms, and utility monitoring systems where long-distance fiber and stable PoE are essential.
Outdoor & Harsh Environment Deployments
Designed for extreme temperatures, electrical noise, and vibration, making it ideal for remote and outdoor industrial installations.
Shipping box information
Product size: 15.8*11.5*6cm
Inner box size: 25.3*20.8*8cm
Product weight: 0.75Kg
Packing weight: 0.9Kg
Master box size: 55.5*40*41cm
Packing quantity: 20Pcs
Packing weight: 20Kg
5. Accessories
|
Industrial Optical Module
|
|
OSPL1G05D
|
1000BASE-SX
|
|
OSPL1G06D
|
1000BASE-SX(1310nm)
|
|
OSPL1G20D
|
1000BASE-LX
|
|
OSPL1G40D
|
1000BASE-EX
|
|
OSBL1G20D-35
|
1000BASE-BX-U(TX 1310 RX1550)
|
|
OSBL1G20D-53
|
1000BASE-BX-D(TX 1550 RX1310)
|
|
Industrial DIN Power Supply
|
|
IM-DAC220/DC48V2.5A
|
AC220V to DC48V2.5A, -40℃～70℃
|
|
IM-DAC220/DC48V5A
|
AC220V to DC48V5A, -40℃～70℃
|
|
IM-DAC220/DC48V10A
|
AC220V to DC48V10A, -40℃～70℃
|
6. FAQ
1, What chip is it based?
Olycom: Realtek
2, Can I customize it?
Olycom: Yes
We support OEM services like logo, model name, label, PVC mask and product parts(mounting kit, power terminal block etc.)
3, Is it managed?
Olycom: No
Its just simple plug-and-play, but we have a managed model(IM-FP266GM)
4. Do you have any certification?
Yes, our company is ISO9001 certified.
We have CE/FCC/RoHS/E-mark/CCC certificates for our models.
5. Do you support OEM&ODM?
Yes, this is our competitive advantage.
