2U High Density DWDM OTN Chassis
Product Features
- Standard 19-inch 2U height
- High integration: a single rack supports 7 general service slots and 1 network management slot
- Unified platform: supports mixed insertion of various business cards, unified network management
- High reliability: support AC and DC power 1+1 protection at the same time
- Good heat dissipation performance: 3 high-performance, high-speed fan designs ensure sufficient heat dissipation
Product Parameters
| Parameter |
Technical indicators |
| Size |
19 inches 2U |
| Number of slots |
8 slots: 1 network management card slot, 7 general service slots |
| power supply |
DC:-36V～-72V,AC:(85-264)V/50～60Hz |
| fan |
3 high-performance, high-speed fans to ensure excellent heat dissipation performance |
| Operating temperature |
-10℃～60℃ |
| Storage temperature |
-40℃～80℃ |
| Relative humidity |
5%～95% non-condensation |
| Product Dimension |
483mm(W)×350mm(D)×88mm(H) |
Front Panel
1) SLOT1 can be inserted into the NMS main control card, and SLOT2～7 can be inserted into various types of service cards
2)FAN slot: Used for heat dissipation of the chassis. When the PWR indicator light is on, it means that the power supply of the fan socket is normal. If the ALM indicator is red, it means that the fan is faulty. Normally, the ALM indicator should be off.
3) Indicator light: PWR: on: normal power supply; off: no power supply or abnormality.
ALM: on: fan failure or overheating; off: normal
Rear Panel
The power supply (PIU) slot is on the back of the device, supporting both AC (APU)/DC (DPU), power supply 1+1 hot backup
Indicator light: PWR: on: normal power supply; off: no power supply or abnormality.
Product Description
The OM3800-2U is designed with a standard 19-inch 2U rack-mounted and plug-in card structure.
- A single chassis provides 8 functional module slots, 2 power supply slots, and 1 fan slot.
- The front panel fiber outlet mode is adopted, and all optical interfaces and network management The interfaces are all designed on the front
- The air duct design adopts the right air inlet and left air outlet mode, and the air inlet is designed on the right side of the chassis.
- The cooling fan unit absorbs cold air into the chassis, and then it is exported from the air outlet on the left side of the chassis.
