OEM ODM 10/100/1000M gigabit Dual Fiber Single Mode SC Connector 60KM Fiber Media Converter

1 pc
MOQ
Negotiable
Price
OEM ODM 10/100/1000M gigabit Dual Fiber Single Mode SC Connector 60KM Fiber Media Converter
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Fiber Media Converter
Fiber Connector: SC Standard, ST/FC Optional
Transmission Distance: 60km
Input Voltage: DC 5V1A With External Power Adapter
Sample: Available
Service: Support OEM/ODM
Highlight:

1000M Fiber Media Converter

,

Dual Fiber Fiber Media Converter

,

60KM Fiber Media Converter
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: Olycom
Certification: CE RoHS FCC
Model Number: TA310-GE/S60
Payment & Shipping Terms
Packaging Details: 1pc in a box
Delivery Time: 3~5 working days
Payment Terms: T/T, PayPal
Supply Ability: 5000pcs/month
Product Description

OEM ODM 10/100/1000M gigabit

Dual Fiber Single Mode SC Connector 60KM Fiber Media Converter


Specification of 10/100/1000mbps optical fiber media Transceiver


Standard

IEEE802.3 (10BASE-T), IEEE802.3u 100BASE-TX/FX (Fast-Ethernet),
IEE802.3z 1000BASE-SX/LX(Gigabit-Ethernet), IEEE802.3x (Flow Control), IEEE802.1q, IEEE802.1p QoS, IEEE802.1d Spanning Tree
10/100/1000BASE-T STP or UTP Category 5/5e/6 cable (Max. 100m)
1000BASE-FX 9/125um singlemode fiber cable (60km)
Conversion Mode / Delay Time Store-and-Forward < 10us, straight-through<0.9us
Flow control Full duplex-flow control, Half duplex-back pressure
RJ-45 Port Auto-MDI/MDIX
Fiber Connector SC standard, ST/FC optional
Wavelength 1550nm
Dimensions 70mm(W) x 93mm(D) x 25mm(H)
Weight Net weight : 0.16kg; Gross weight : 0.42kg
Input Voltage DC 5V1A with External power adapter
Power Consumption <2.5W
MTBF 50,000 hours
BER <1/1000000000
MAC Address Table 1K
Buffer Size 128K
Operating Temperature 0℃~50℃
Storage Temperature -40℃~70℃
Storage Humidity 5%~90% non-condescending



Key Features of Media Converter



  • 10/100/1000Mbps autosensing, auto-MDI/MDIX
  • 1600byte super data packet transmission
  • Full duplex-flow control, Half duplex-back pressure
  • Full- positioned LEDs to indicate power and network status
  • Available for 14 slots rack



Application

OEM ODM 10/100/1000M gigabit Dual Fiber Single Mode SC Connector 60KM Fiber Media Converter 0
Ordering Details


TA310G-GE/M05 10/100/1000M, Standalone, dual fiber, multimode, SC, 0.5km, external power supply
TA310G-GE/S20 10/100/1000M, Standalone, dual fiber, single mode, SC, 25km, external power supply
TA310G-GE/S40 10/100/1000M, Standalone, dual fiber, single mode, SC, 40km, external power supply
TA310G-GE/S60 10/100/1000M, Standalone, dual fiber, single mode, SC- 60km, external power supply
TA310G-GE/S80 10/100/1000M, Standalone, dual fiber, single mode, SC- 80km, external power supply
TA310G-GE/S100 10/100/1000M, Standalone, dual fiber, single mode, SC, 100km, external power supply
TA310G-GE/S120 10/100/1000M, Standalone, dual fiber, single mode, SC, 120km, external power supply



FAQ:



1 Q: What is your lead time?

A:It usually takes 3~5 working days to produce and then will send goods.



2 Q: Whats Your Main Products?

A: POE Switch, Fiber Media Converter, Video Fiber Converter, Industrial Managed Switch, WDM/OTN Transmission Series.



3 Q: Please tell me something about your MOQ

A: Our MOQ is 1 Pcs/Pair based on USD or EUR terms.



4 Q: Something about pricing.

A: Good quality components for our products. Low prices for big and repeat orders.



5 Q: Can you do OEM/ODM service?

A: Yes,Customized products is available.We have very strict quanlity control system.
