Industrial POE Switch with 8 Port POE 4 SFP Ports and Vitesse Chip Managed Network Switch

1 pc
MOQ
Negotiable
Price
Industrial POE Switch with 8 Port POE 4 SFP Ports and Vitesse Chip Managed Network Switch
Features Gallery Product Description Ratings & Review Request A Quote
Features
Specifications
Product Name: 12 Port Managed Industrial POE Switch
Function: LACP, QoS, SNMP, VLAN Support
PoE Ports: 8 Ports Support Poe
Network Distance: 100 Meters
Dimension: 158*114.8*60mm
Highlight:

8*10/100/1000Base-T POE Ethernet Switches

,

Managed Network Industrial POE Ethernet Switches

,

8 PoE Managed Network Switches
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: Olycom
Certification: CE RoHS FCC
Model Number: IM-FP488GW
Payment & Shipping Terms
Packaging Details: 1pc in a box
Delivery Time: 3~5 working days
Payment Terms: T/T,PayPal
Supply Ability: 5000pcs/month
Product Description
Industrial POE Ethernet Switches
Managed Network Switches with 4×1000 Base-X and 8×10/100/1000Base-T ports featuring Vitesse chip technology
Key Features
  • Cable diagnosis with fault point location capability
  • IEEE802.3az EEE (Energy Efficient Ethernet) management for optimized power consumption
  • Support for STP, RSTP, MSTP, and ITU-T G.8032 Ethernet Protection Ring (EPR)
  • Advanced QoS with transport classification, CoS, bidirectional bandwidth control, and storm suppression
  • Comprehensive VLAN support including IEEE802.1q, port-based, MAC-based, IP subnet, Protocol VLAN, VLAN convert, and MVR
  • Dynamic IEEE802.3ad LACP and static link aggregation
  • IGMP/MLD snooping V1/V2/V3 with filtering, modulation, and searching capabilities
  • Enhanced security with IEEE802.1X, RADIUS, ACL, TACACS+, HTTP/HTTPS, and SSL/SSH v2
  • Multiple management options: Cisco-like CLI, Web management, SNMP v1/v2c/v3, Telnet
  • Software upgrade via TFTP and HTTP with firmware redundancy protection
  • DHCP client/Relay/Snooping with option 82 support
  • RMON, MIB II, mirror image, event log, DNS, NTP/SNTP, and IEEE802.1ab LLDP
  • IPv6 support for Telnet server, ICMP v6, SNMP, HTTP, SSH/SSL, NTP/SNTP, TFTP, QoS, and ACL
Industrial POE Switch with 8 Port POE 4 SFP Ports and Vitesse Chip Managed Network Switch 0
Technical Specifications
Product Name10/100/1000Mbps Managed Industrial POE Fiber Switch (4F+8TP)
Model No.IM-FP488GW
Port Configuration4 × 1000Mbps SFP ports (SM: 1310nm/1550nm, 20Km; 1490nm/1550nm, 40-120Km; MM: 1310nm, 2Km); 8 × 10/100/1000M UTP RJ45 (MDI/MDIX auto-sensing)
Standards ComplianceIEEE 802.3, 802.3U, 802.3ab, 802.3z, 802.1d STP, 802.1w RSTP, 802.1s MSTP, ITU-T G.8023 EPR/Y.1344, 802.1Q, 802.1X, 802.3ad, 802.3x, 802.3af, 802.3at, 802.1ad, 802.1p, 802.1ab, 802.3az
VLAN ID4096
Jumbo Frame9.6KB
MAC Address Table Size8K
Switching FeaturesStorage and forward transmission mode; 58Gbps system bandwidth (non-blocking)
Network Media10BASE-T: CAT3/4/5 UTP (≤100m); 100/1000BASE-TX: CAT5+ STP (≤100m); SFP ports: 20Km, 40Km, 60Km, 80Km, 100Km transmission distances
LED IndicatorsPower, network, fiber
Power SupplyPOE input voltage: 48V (max 52V); Single PoE output power: 15.4W (port 1-8)
Operating EnvironmentTemperature: -40° to 75°C; Storage: -40° to 85°C; Humidity: 10%-90% non-condensing; Storage humidity: 10%-95% non-condensing
Industry StandardsEMI: FCC Part 15 Class A, EN 55022 Class A; EMS: EN 61000-4-2/3/4/5/6/8; Traffic Control: NEMA-TS2; Vibration, Freefall, Shock: IEC 60068-2-6/32/27; Rail Traffic: EN 50121-4
Safety CertificationsCE Mark commercial; CE/LVD EN60950
Mechanical InformationCorrugated metal shell; IP40 safety class; Dimensions: 158 × 114.8 × 60mm; DIN-rail mounting
Warranty3 years
Application Scenarios
Industrial POE Switch with 8 Port POE 4 SFP Ports and Vitesse Chip Managed Network Switch 1
Manufacturing Advantages
  1. 20 years of manufacturing experience with robust factory capabilities
  2. Professional R&D team with engineers averaging 5+ years of experience
  3. Fast dispatch - orders below 10 pieces delivered within 3 days
  4. Low MOQ accepted - single piece orders available
  5. Comprehensive 3-year warranty on all industrial-grade products
