Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches

1 pc
MOQ
Negotiable
Price
Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: 12 Port Managed Industrial POE Switch
Function: LACP, QoS, SNMP, VLAN Support
PoE Ports: 8 Ports Support Poe
Network Distance: 100 Meters
Dimension: 158*114.8*60mm
High Light:

8*10/100/1000Base-T POE Ethernet Switches

,

Managed Network Industrial POE Ethernet Switches

,

8 PoE Managed Network Switches

Basic Infomation
Place of Origin: Guangdong, China
Brand Name: Olycom
Certification: CE RoHS FCC
Model Number: IM-FP488GW
Payment & Shipping Terms
Packaging Details: 1pc in a box
Delivery Time: 3~5 working days
Payment Terms: T/T, PayPal
Supply Ability: 5000pcs/month
Product Description

Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T

Managed Network Switches



Introduction



IM-FP488GW series is the 10/100/1000Mbps managed industrial POE fiber switch, comply with IEEE802.3af/at, power on POE IP cameras through the Ethernet cable, simple construction, power range up to 100 meters, operating temperature-40 ℃ to + 85 ℃, meet IP40 protection degree and EMC industrial grade requirements, DIN rail installation, pass through dangerous environmental certification and comply with FCC and CE standards. The reliable industrial grade design could ensure continuous and stable operation of the automation system.



Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 0Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 1

Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 2

Key Features



  • Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 3 Support cable diagnosis and can locate the fault point
  • Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 4 Support IEEE802.3az EEE (Energy Efficient Ethernet) Management, optimize power consumption
  • Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 5 Support STP, RSTP, MSTP, ITU-T G.8032 Ethernet Protection Ring(EPR)
  • Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 6 Support Qos, transport classification Qos, Cos, bandwidth control(input/output direction), storm suppression ,differentiated services
  • Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 7 Support IEEE802.1q VLAN,VLAN port ,based Mac VLAN,IP subnet VLAN, Protocol VLAN,VLAN convert, MVR
  • Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 8 Support dynamic IEEE802.3ad LACP link aggregation, static link aggregation
  • Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 9 Support IGMP/MLD snooping V1/V2/V3, IGMP filtrating/ modulating, IGMP searching
  • Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 10 Support IGMP agent report, MLD snooping
  • Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 11 Safety: based on port and Mac IEEE802.1X, RADIUS, ACL, TACACS+,HTTP/HTTPS, SSL/SSH v2
  • Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 12 Support Cisco® like CLI, Web management, SNMP v1/v2c/v3, Telnet
  • Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 13 Support software upgrade via TFTP and HTTP, firmware redundancy prevents upgrade failing
  • Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 14 Support DHCP client/Relay/Snooping/Snooping option 82/Relay option 82
  • Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 15 Support RMON, MIB II, mirror image, event log, DNS, NTP/SNTP, IEEE802.1ab LLDP
  • Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 16 Support IPV6 Telnet server /ICMP v6, SNMP, HTTP, SSH/SSL, NTP/SNTP,TFTP, QoS, ACL.





Specification managed industrial POE fiber switch



Product Name 10/100/1000Mbps Managed Industrial POE Fiber Switch (4F+8TP)
Model No. IM-FP488GW
Port

4 x 1000Mpbs SFP port

SM:1310nm/1550nm,20Km ;1490nm/1550nm, 40~120Km; MM:1310nm, 2Km; 8x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing)

Standard IEEE 802.3, IEEE802.3U, IEEE802.3ab, IEEE802.3z, IEEE802.1d STP, IEEE802.1w RSTP, IEEE802.1s MSTP, ITU-T G.8023 EPR/Y.1344, IEEE802.1Q, IEEE802.1X, IEEE802.3ad, IEEE802.3x, IEEE802.3af, IEEE802.3at, IEEE802.1ad, IEEE802.1p, IEEE802.1ab, IEEE802.3az
VLAND ID 4096
Jumbo Frame 9.6KB
MAC Address Table Size 8K
Switching features

Transmission mode:storage and forward

System bandwidth:58Gbps (non-traffic jam)

Network media

10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)

100/1000BASE-TX: CAT5 or above shielded twisted pair(≤100m)

SFP port,transmission distance: 20Km,40Km,60Km,80Km,100Km

LEDs Power, network, fiber
Power supply

POE power supply input voltage: 48V (max 52V),

Single PoE power supply output power: 15.4W (port 1~8)

(802.3at standards required special instructions)

Environment Working Temp:-40°~ 85°C ; Storage Temp:-40°~ 85°C;Working humidity:10%~90%, non-condensing; Storage humidity:10%~95%, non-condensing
Industry Standards

EMI:FCC Part 15 Subpart B Class A,EN 55022 Class A

EMS:EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3, EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3, EN 61000-4-8; Traffic Control:NEMA-TS2; Vibration:IEC 60068-2-6; Freefall:IEC 60068-2-32; Shock:IEC 60068-2-27; Rail Traffic:EN 50121-4

Safety CE Mark ,commercial ; CE/LVD EN60950
Mechanical information

Shell:Corrugated metal shell; Safety class:IP40;

Dimension:158 x 114.8 x 60mm;

Mounting method:Din-rail mounting

Warranty Replacement within 1year; 5 years repairing


Application



Industrial POE Ethernet Switches 4*1000 Base-X 8*10/100/1000Base-T Managed Network Switches 17

Advantage:

1. Manufacturing: We are a powerful factory and has been in this industry about 20 years

2. Professional R&D center: We have a professional and independent R&D team. Most our engineers have more than 5 years experience.

3. Fast dispatch: Most of the products are in stock. Below 10pcs can arrange delivery with 3 days.

4. Small order accepted: Low MOQ accepted. 1pcs are available.

5. Insurance: all products 3 years warranty.
