Outdoor POE Switch Fast Ethernet 2 Port 10/100Mbps 1 RJ45+1 Fiber Sfp Fiber Media Converter

1 pc
MOQ
Negotiable
Price
Outdoor POE Switch Fast Ethernet 2 Port 10/100Mbps 1 RJ45+1 Fiber Sfp Fiber Media Converter
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: 2 Port Fiber Media Converter
Power Adapter Voltage: AC 110V-240V
Data Rate: 10/100Mbps
PoE Output Power: 15.4W/30W
Sample: Available
High Light:

1 Fiber Sfp Fiber Media Converter

,

1 RJ45 Fiber Media Converter

,

POE Switch Fiber Media Converter

Basic Infomation
Place of Origin: Guangdong, China
Brand Name: Olycom
Certification: CE RoHS FCC ISO9001
Model Number: IM-PC111FE
Payment & Shipping Terms
Packaging Details: 1pc in a box
Delivery Time: 3~5 working days
Payment Terms: T/T, PayPal
Supply Ability: 5000pcs/month
Product Description

Outdoor POE switch Fast Ethernet 2 port 10/100Mbps 1 RJ45+1 fiber sfp Fiber Media Converter


Introduction


IM-PC111FE series is the 10/100Mbps industrial POE fiber media converter, comply with IEEE802.3af/at, power on POE IP cameras through the Ethernet cable, simple construction, power range up to 100 meters, operating temperature-40 ℃ to + 85 ℃, meet IP40 protection degree and EMC industrial grade requirements, DIN rail installation, pass through dangerous environmental certification and comply with FCC and CE standards. The reliable industrial grade design could ensure continuous and stable operation of the automation system.




Key Features


  • Support power on POE IP cameras through the wireless access point (AP) of 5 categories of Ethernet cable.
  • IEEE 802.3af /at power on to 1 RJ45 port
  • 1 x 10/100Mbps Auto-sensing RJ45 port
  • 1 x 100Mbps fiber port
  • 4KV Ethernet surge protection, adapt to a harsh outdoor environment
  • Support Auto MDI/MDIX
  • Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Back pressure standard
  • IEEE 802.3 10Base-T and IEEE 802.3u 1000Base-TX compliant
  • Max power to15.4W under af standard, 30W under at standard to each PoE port
  • Detect the PoE models of electrical equipment.
  • A store-and-forward switching mechanism
  • Operating environment temperature:-40 ° ~85 ° c




Specification of Industrial Fiber Media Converter

Product Name10/100Mbps Industrial POE Fiber Media Converter (1F+1TP)
Model No.IM-PC111FE
Port

1 x 100Mpbs fiber port
SM:1310nm/1550nm,20Km
1490nm/1550nm,40~120Km
MM:1310nm,2Km
1x10/100M UTP RJ45(Support MDI/MDIX auto-sensing)

Switching features

Transmission mode:storage and forward
System bandwidth:40Gbps (non-traffic jam)

Network media

10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)
100BASE-TX: CAT5 or above shielded twisted pair(≤100m)
Fiber port,transmission distance: 20Km,40Km,60Km,80Km,100Km

LEDsPower, network, fiber
Power supply

POE power supply input voltage: 48V (max 52V),
Single PoE power supply output power: 15.4W (port 1)
(802.3at standards required special instructions)

Environment

Working temperature:-40°~ 85°C
Storage temperature:-40°~ 85°C
Working humidity:10%~90%,non-condensing
Storage humidity:10%~95%,non-condensing

Industry Standards

EMI:FCC Part 15 Subpart B Class A,EN 55022 Class A
EMS:EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3,EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3,EN 61000-4-8
Traffic Control:NEMA-TS2
Vibration:IEC 60068-2-6
Freefall:IEC 60068-2-32
Shock:IEC 60068-2-27
Rail Traffic:EN 50121-4

Safety

CE Mark ,commercial
CE/LVD EN60950

Mechanical information

Shell:Corrugated metal shell
Safety class:IP40
Dimension: 113.8 x 93 x 34.9mm
Mounting method:Din-rail mounting

WarrantyReplacement within 1 year; 3 years repairing


Packing box of switch

Outdoor POE Switch Fast Ethernet 2 Port 10/100Mbps 1 RJ45+1 Fiber Sfp Fiber Media Converter 0

  • Put the product in an ESD Bag, then placed in PE foams with outer carton packaging.
  • The standard packing usually contains a main device, a warranty card and a user manual.
  • Packing box dimension for 1pc: 23*16.5*5.8cm
  • 40pcs in a packing box of 67*33*47cm dimension.





FAQ
1.Whats Your Main Products?
POE Switch,industrial POE Switch,Ethernet Switch, WDM, OTN, optical bypass

2.Which Payment Terms Do You Accepte?
We Can Accept T/T, Paypal

3.How Long Can I Expect To Get The Sample ?
Usually Within 3 Days But Depends On Your Requirements .

4.How About The Shipping ?
We Will Deliver The Goods With Internation Express Like FEDEX,DHL,UPS,TNT And So On

5.How About The After-sales Services?
Professional Services Team,24 Hours On Line.
