6 Port Gigabit Managed Industrial POE Switch DC 48V Input 4 RJ45+2 SFP With Din-Rail

1 pc
6 Port Gigabit Managed Industrial POE Switch DC 48V Input 4 RJ45+2 SFP With Din-Rail
Features Gallery Product Description Request A Quote
Product Name: 6 Port Managed Industrial POE Switch
Power Input: DC48V
Transmission Distance: 2KM-120KM
Use: Smart City
Network Medium: Cat5 (UTP) Or More
MOQ: 1
High Light:

Gigabit Managed Industrial POE Switch


6 Port Industrial POE Switch

Basic Infomation
Place of Origin: Guangdong, China
Brand Name: Olycom
Certification: CE RoHS FCC ISO9001
Model Number: IM-FP244GM
Payment & Shipping Terms
Packaging Details: 1pc in a box
Delivery Time: 3~5 working days
Payment Terms: T/T, PayPal
Supply Ability: 5000pcs/month
Product Description

6 port Gigabit managed industrial poe switch DC 48V input 4 RJ45+2 SFP with Din-rail

Key Features of managed switch

  • Support power on POE IP cameras through the wireless access point (AP) of 5 categories of Ethernet cable.
  • IEEE 802.3af/at/bt power on to 1 ~ 4 RJ45 ports
  • 4 x 10/100/1000Mbps Auto-sensing RJ45 ports
  • 2 x 1000Mbps SFP fiber port
  • 4 KV Ethernet surge protection, adapt to a harsh outdoor environment
  • Support Auto MDI/MDIX
  • Flow control mode: full duplex with IEEE 802.3x standard,
  • half-duplex with Back pressure standard
  • IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant
  • A store-and-forward switching mechanism
  • Operating environment temperature:-40 ° ~85 ° c
  • Support bus/star topology, ring structure, support ITU-T G.8032/Y.1344 ERPS
  • Support SNMPv1, v2, v3, Web management, support user login password protection and other device configuration methods
  • Support ACL, port-based MAC filtering, MAC address binding, port-based 802.1x authentication, system automatic defense, prevent DDOS and other attacks;
  • Support VLAN: support port VLAN and 802.1Q Tag
  • Support QoS 4-level priority, static LACP, support port-based one-way and two-way traffic mirroring
  • Support IGMP Snooping v1/v2, port bandwidth control, broadcast storm suppression
  • Support SNTP protocol
  • Support MIB library opening to meet the requirements of operation and maintenance
  • Support SNMPv3, IEEE 802.1X, HTTPS and SSH, enhancing network security
  • Support WEB, CLI, Telnet, Windows utility and SNMP management methods
  • Reset: Support restart and restore default configuration



Specification of Industrial Full Gigabit Switch

Product Name 10/100/1000Mbps Managed Industrial POE Fiber Switch (2F+4TP)
Model No. IM-FP244GM

2 x 1000Mpbs SFP port

SM:1310nm/1550nm,20Km ;1490nm/1550nm, 40~120Km; MM:1310nm, 2Km; 4x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing)

Standard IEEE 802.3i, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x , IEEE 802.1Q VLAN Tagging, IEEE 802.1p CoS, IEEE 802.1X, IEEE 802.3ad, ITU-T G.8032 ERPS, IEEE802.3af, IEEE802.3at

☆Support VLAN: 802.1Q VLAN (4K), Port-based VLAN

☆ Jumbo frame processing: 9k

☆ Report buffer: 64K

☆ Broadcast storm suppression: support broadcast, multicast, unknown unicast suppression

☆ Flow control: Adopt IEEE802.3x negotiation flow control, CAR function, speed limit step size is 1Kb

☆ Ring network function: support ITU-T G.8032 /Y.1344 ERPS

☆ Multicast protocol: IGMPv1/2/3 Snooping

☆ Port management: support port isolation and port aggregation

☆ DHCP management: support DHCP Snooping, option 82

☆ QoS mechanism: 802.1p; support port default priority marking, each port has at least 4 queues with different priorities

☆ Security: login access authentication, login password modification, MAC address filtering, support dynamic or static MAC address learning / support ARP learning function off and on, ARP message speed limit / support IP+MAC+ port manual and automatic scanning binding Set IEEE 802.1x (Port based, MAC based), can transparently transmit 802.1x data packets/port loop detection

Switching Features

Exchange capacity: 12Gbps Packet forwarding rate: 8.928Mpps

MAC address table: 2K Swap delay: <5μs

Transmission method: store and forward

Power supply

Input voltage:DC 48-52V; Support POEaf/at/bt (15.4W/30W/60W)

Reverse connection: support

Overload protection: support

Redundant protection: support


Working Temp:-40°~ 85°C ; Storage Temp:-40°~ 85°C;

Working humidity:5%~95%, non-condensing

Industry Standards

EMI:FCC Part 15 Subpart B Class A,EN 55022 Class A

EMS:EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3,EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3,EN 61000-4-8

Traffic Control:NEMA-TS2 Vibration:IEC 60068-2-6

Freefall:IEC 60068-2-32 Shock:IEC 60068-2-27 Rail Traffic:EN 50121-4

Mechanical information

Shell:Corrugated metal shell; Safety class:IP40

Dimension:113.8 x 93 x 34.9mm

Mounting method:Din-rail mounting

Warranty Replacement within 1year; 3 years repairing
