10G BIDI SFP Module 10km 1270nm/1330nm CWDM DFB, DDM Compatible With Ciso

1 pc
10G BIDI SFP Module 10km 1270nm/1330nm CWDM DFB, DDM Compatible With Ciso
Features Gallery Product Description Request A Quote
Product Name: BiDi SFP+ Transceiver
Certificaiton: CE FCC ROHS Compliance
Wavelength: 1270nm/1330nm
Power Supply: 3.3V
Application: Telecommunication Network
High Light:

10G BIDI SFP Module


10km BIDI SFP Module

Basic Infomation
Place of Origin: Guangdong, China
Brand Name: Olycom
Certification: CE RoHS FCC ISO9001
Model Number: OSBLXG10D-23/32
Payment & Shipping Terms
Packaging Details: 1pc in a box
Delivery Time: 3~5 working days
Payment Terms: T/T, PayPal
Supply Ability: 5000pcs/month
Product Description

10g Bidi Sfp Module Price10km 1270nm/1330nm CWDM DFB, DDM Compatible With Ciso


OLYCOM’ OSBLXG10D-23 & OSBLXG10D-32 Bi-directional 10Gb/s (SFP+) transceivers are compliant with the current SFP+ Multi-Source Agreement (MSA) Specification. They comply with 10GBASE-LR/LW Ethernet, SONET OC-192 / SDH and 10G Fiber Channel 1200-SM-LL-L. Digital diagnostics functions are available via a 2-wire serial interface, as specified in the SFP+ MSA.
Key Features:
Supports 9.95Gb/s to 11.3Gb/s bit rates
Hot-pluggable SFP+ footprint
Single LC for Bi-directional Transmission
Maximum link length of 10km
Built-in 1270/1330 WDM Filter
Uncooled 1270nm or 1330nm CWDM DFB Laser.
Power dissipation <1.5W
No Reference Clock required
Built-in digital diagnostic functions
Temperature range 0°C to 70°C
Very low EMI and excellent ESD protection
RoHS Compliant Part


Absolute Maximum Ratings

Parameter Symbol Min. Typical Max. Unit
Storage Temperature TS -40   +85 °C
Supply Voltage VCCT, R -0.5   4 V
Relative Humidity RH 0   85 %


Recommended Operating Environment:

Parameter Symbol Min. Typical Max. Unit
Case operating Temperature TC -5   +70 °C
Supply Voltage VCCT, R +3.135   +3.465 V
Supply Current ICC     350 mA
Power Dissipation PD     1.5 W


Electrical Characteristics (TOP = 0 to 70 °C, VCC = 3.135 to 3.465 Volts)

Parameter Symbol Min Typ Max Unit Note
Differential input voltage swing   180   700 mVpp 1
Transmit Disable Input H VIH 2.0   Vcc+0.3 V
L VIL 0   0.8 V
Transmit Enable Output H VOH 2.4   Vcc+0.3 V
L VOL 0   0.4 V 2
Input Differential Impedance Zin 80 100 120 Ω
Differential output voltage swing   300   850 mVpp 3
LOS Output H VOH 2.4   Vcc+0.3 V 2
L VOL 0   0.4 V
Output Differential Impedance Zon 80 100 120 Ω


1. Manufacturing: We are a powerful factory and has been in this industry about 10 years
2. Professional RD center: We have a professional and independent RD team. Most our engineers have more than 5 years experience.
3. Fast dispatch: Most of the products are in stock. Below 10pcs can arrange delivery with 3 days.
4. Small order accepted: Low MOQ accepted. 1pcs are availabel.
5. Insurance: all products 3 years warranty.
