Gigabit Managed Layer 2 Network Switch 24 Port Fanless WEB CLI SNMP Supported CE FCC

1 pair
MOQ
Negotiable
Price
Gigabit Managed Layer 2 Network Switch 24 Port Fanless WEB CLI SNMP Supported CE FCC
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: 24 Port GIgabit Managed Ethernet Switch
Fiber: 16*1G SFP Slot
Copper: 8*1G Network
Management: Layer 2
Installation: 1U Rack Compatible
Customization: Support
Highlight:

Gigabit Managed Layer 2 Network Switch

,

24 Port Layer 2 Network Switch

,

Fanless Layer 2 Network Switch

Basic Infomation
Place of Origin: Shenzhen, China
Brand Name: Olycom
Certification: CE RoHS FCC
Model Number: TA71608W-GE
Payment & Shipping Terms
Packaging Details: 1 pair in a carton, 2kg(G.W)
Delivery Time: 3~8 working days
Payment Terms: T/T, Paypal
Supply Ability: 1000pcs/month
Product Description

24 Port 1G Manageable Fiber Ethernet Switch



Key Features

1. Hybrid Hardware Design
16 gigabit SFP fiber slots + 8 copper RJ45 ports, full wire-speed non-blocking forwarding, jumbo frame up to 10056 bytes, per-port flow control, auto-adaptive port speed.

2. Multi Unified Management
Support Web(HTTPS)/CLI/SSH/SNMP/RMON five management modes, built-in NTP time sync, remote syslog log upload, one-click config import/export & firmware upgrade.

3. Multiple Ring & Link Redundancy
ERPS (20ms fast failover), STP/RSTP/MSTP, static & dynamic LACP link aggregation, LLDP neighbor discovery, private loop protection to avoid broadcast storms.

4. Multi-Layer VLAN & Multicast Control
802.1Q Trunk/Access/Hybrid VLAN, MAC/IP/Protocol VCL hierarchical isolation, MVR cross-VLAN multicast, IGMP Snooping with fast leave to save bandwidth.

5. Full Traffic QoS Control
8 hardware priority queues, 802.1P/DSCP marking, multiple scheduling algorithms, ingress/egress port bandwidth limit.

6. Industrial-Grade L2 Security Suite
DHCP Snooping + ARP Inspection + IP Source Guard anti-spoofing, 512-entry ACL access control, port security MAC binding, 802.1X authentication, broadcast storm suppression, port isolation.

7. Practical Diagnostic Tools
Port mirroring traffic capture, built-in ping test, full port traffic & error packet statistics, real-time device status monitoring.

Specification


Service Ports

16 * 1000 Base-X SFP ports;

8 * 10/100/1000MBase-T ports;

Management Port

1 Console

Reset Key

1

Switching Capacity

256Gbps

Packet Forwarding Capacity

96Mpps

Operation Temperature

-20~50°C

Storage Temperature

-40~70°C

Operation Humidity

10%~90%(non-condensing)

Storage Humidity

5%~95%(non-condensing)

Dimensions

440(L)×285(W)×44.5(H)mm

Weight

<5Kg

Input Voltage(AC)

AC:110~240V/50~60Hz

Power Consumption

<30W



Protocol and Standards

IEEE 802.3, 10 Base-T Ethernet;

IEEE 802.3u,100 BASE-TX;

IEEE 802.3ab,1000 BASE-T;

IEEE 802.3z,1000 BASE-X;

IEEE 802.3az,EEE(Energy Efficient Ethernet);

MAC Address

32K MAC addresses

VLAN

Based Port VLAN

Up to 4096 VLAN

VLANs based on IEEE 802.1q

Spanning Tree

STP Spanning Tree Protocol

RSTP Rapid Spanning Tree Protocol

MSTP Multiple Spanning Tree Protocol

Port Aggregation

14 aggregation groups,each containing up to 16 ports;

Port Mirroring

Send and receive two-way port mirroring

Ring network protocol

ERPS

Support ring protection

Port Isolation

Downlink ports are isolated from each other and can communicate with uplink

Port stream control

Half duplex based on backpressure control

Full duplex based on PAUSE frames

Port speed limit

Port Based Input / Output Bandwidth Management

Multicast control

IGMPv1/2/3 and MLDv1/2 Snooping

DHCP

DHCP Snooping

DHCP Server

Storm suppression

Storm suppression for unknown Unicast, multicast, multicast, broadcast type

Storm suppression based on bandwidth regulation and storm filtering

Security features

User port + IP address + MAC address

ACL Based on IP and MAC

Security limit on the number of MAC addresses based on ports

IP Source Guard

IEEE 802.1x

Radius

QOS

802.1 P Port Queue Priority Algorithm

Cos/Tos,QOS tags

WRR (Weighted Round Robin)

Ping Detection

IPv4/IPv6 Ping Detection

Modalities for consultation

Port automatic negotiation

System maintenance

Detection of connectivity

Upgrade package upload

See System log

WEB factory configuration restored

Management

WEB-based interface management

Telnet

CLI Management (Command Line Interface)

SNMP


Application

  • Smart City Video Surveillance: Long-distance fiber ring networking, MVR multicast stream optimization
  • Industrial Automation: ERPS ultra-fast self-healing ring, isolated control network
  • Power & New Energy Stations: Stable fiber transmission, unified time log management
  • Enterprise & Campus: Department VLAN division, identity access authentication
  • Smart IoT & Pipe Gallery: Scattered sensor long-distance fiber aggregation
  • Small Server Room: Link aggregation for storage, traffic audit via port mirror
