6 Port Industrial Ethernet Switch Gigabit Network 100/1000M SFP Fiber Unmanaged Realtek Chip

1 piece
MOQ
Negotiable
Price
6 Port Industrial Ethernet Switch Gigabit Network 100/1000M SFP Fiber Unmanaged Realtek Chip
Features Gallery Product Description Ratings & Review Request A Quote
Features
Specifications
Name: 6 Port 100/1000M Industrial Ethernet Switch
Fiber Port: 2*100/1000M SFP Slots
Copper Port: 4*100/1000M RJ45
Input Voltage: DC12-52V
Feature: Unmanaged, Non-PoE
Customization: Yes
Highlight:

60Km transmission 6 Port Managed Switch

,

Waterproof 6 Port Managed Switch

,

60Km transmission industrial SFP Switch
Basic Infomation
Place of Origin: Shenzhen, China
Brand Name: OLYCOM
Certification: CE, RoHS, FCC
Model Number: IM-FS240GE
Document: OLYCOM Industrial Networkin...24.pdf
Payment & Shipping Terms
Packaging Details: One unit device and one user manual are inside one box , sealed and well protected.
Delivery Time: 5-8 days
Payment Terms: T/T, PayPal
Supply Ability: 6000 sets per month
Product Description

6 Port Gigabit Network Industrial Fiber Switch



Key Features of Gigabit Switch Unmanaged



  • 2x100/1000Mbps Auto-sensing SFP fiber ports
  • 4x10/100/1000Mbps Auto-sensing RJ45, IEEE 802.3af/at power on to 1~ 4 ports
  • 6KV Ethernet surge protection, adapt to a harsh outdoor environment
  • Support Auto MDI/MDIX
  • Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Back pressure standard
  • IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant
  • DIN rail or Wall installation
  • Comply with FCC and CE standards
  • A store-and-forward switching mechanism
  • Operating environment temperature: -40°C～75°C



Technical Information of Industrial Network Switch



Product Name 10/100/1000Mbps Industrial Fiber Switch(2F+4TP)
Model No. IM-FS240GE
Port

2x100/1000M SFP Fiber

SM: 1310nm/1550nm, 20Km; 1490nm/1550nm, 40~120Km

MM: 1310nm, 2Km; 850nm, 500-meter

4x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing)

1x6-PIN Power Terminal Block
Protocol

IEEE 802.3(10Base-T)

IEEE 802.3u(100Base-TX)

IEEE 802.3ab(1000Base-TX)
Switching Features

Transmission mode: storage and forward

Forwarding delay: <10us

System bandwidth: 12Gbps (non-traffic jam)

Forwarding rate: 17.856Mmps

MAC: 4K

Packet buffer size: 1.75Mb
Network Media

10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)

100/1000BASE-TX: CAT5 or above shielded twisted pair(≤100m)
LEDs

Power, Fiber, Network, PoE

PWR: Power



Fiber: FX1, FX2

On: transmission is normal

Off: transmission is NOT normal(faulty optical module or disconnected)



Copper orange: PoE indicator

On:PoE is working

Off:PoE is not working or this is Non-PoE device



Copper green: Speed indicator

On:transmission speed is 1000Mbps

Blinking: in transmission

Off:Disconnected or working speed is 10/100Mbps



Environment

Working temperature: -40°C～75°C

Storage temperature: -40°C～85°C

Working humidity: 10%～90%, non-condensing

Storage humidity: 10%～95%, non-condensing
Industry Standards

ESD: IEC61000-4-2, ±15KV air, ±6KV contact

EFT: IEC61000-4-4, General ±6KV

Surge: IEC61000-4-5, Differential ±2KV, Common±6KV
Certification

CE-EMC: EN 55032:2015+AC: 2016+A1:2020+A11: 2020

EN 55035:2017+A11: 2020/EN IEC 61000-3-2:2019/A1: 2021

EN 61000-3-3: 2013/A2: 2021/AC:2022

CE-LVD: EN IEC 62368-1: 2020+A11:2020

FCC: 47 CFR FCC Part 15 Subpart B(Class B) ANSI C63.4: 2014
Mechanical information

Shell: Corrugated metal shell, IP40 grade level

Dimension: 114*93*35mm

Mounting method: Din-rail/Wall mounting

Weight: 0.35Kg/0.45Kg(Net/Gross)
Warranty 3 years, lifetime technical support



6 Port Industrial Ethernet Switch Gigabit Network 100/1000M SFP Fiber Unmanaged Realtek Chip 0



Application of Fiber Optic Switch



6 Port Industrial Ethernet Switch Gigabit Network 100/1000M SFP Fiber Unmanaged Realtek Chip 1



FAQ



1, What chip is it based?

Olycom: Realtek



2, Can I customize it?

Olycom: Yes

We support OEM services like logo, model name, label, PVC mask and product parts(mounting kit, power terminal block etc.)



3, Can I connect it with 10/100M devices?

Olycom: Yes

All ports are 10/100/1000M auto-sensing



4, Is it managed?

Olycom: No

Its just simple plug-and-play, but we have a managed model(IM-FP244GM)






6 Port Industrial Ethernet Switch Gigabit Network 100/1000M SFP Fiber Unmanaged Realtek Chip 2

6 Port Industrial Ethernet Switch Gigabit Network 100/1000M SFP Fiber Unmanaged Realtek Chip 3
6 Port Industrial Ethernet Switch Gigabit Network 100/1000M SFP Fiber Unmanaged Realtek Chip 4
