3 Port Compact Gigabit Ethernet Switch Hardened With Industrial Temp 24V

3 Port Compact Gigabit Ethernet Switch Hardened With Industrial Temp 24V
Features Gallery Product Description Request A Quote
Product Name: Rugged Gigabit Sfp Ethernet Switch
Function: Unmanaged, Without POE
Weight: 0.35kg
Operating Temperature: -40 ℃ To + 85 ℃
Warranty: 3 Years
Dimension: 114*93*35mm
High Light:

Compact Gigabit Ethernet Switch


Hardened Gigabit Ethernet Switch


24V Industrial Network Switch

Basic Infomation
Place of Origin: Shenzhen, China
Brand Name: Olycom
Certification: CE ISO9001 RoHS FCC
Model Number: IM-FS120GE V1
Payment & Shipping Terms
Packaging Details: 1pc in a box, 0.45kg gross weight
Delivery Time: 4~8 working days
Payment Terms: T/T, PayPal
Supply Ability: 3000pcs/month
Product Description

Industrial Compact Ethernet 4 Port Gigabit unmanaged switch


Key Features of industrial switch 24v


Port: 1 Fiber to 2 UTP

Speed: 2 x 10/100/1000Mbps auto-sensing RJ45 ports, support Auto MDI/MDIX

Optical: 1 x 1000Mbps SFP fiber port, it is fine to choose 1*9 fixed module

Certification: comply with FCC and CE standards

Mounting method: din rail, wall or desktop use

Voltage input: DC9V~DC52V

3 Port Compact Gigabit Ethernet Switch Hardened With Industrial Temp 24V 0


Specification of hardened network switch


Product Name 10/100/1000Mbps Industrial Fiber Switch (1F+2TP)

1 x 1000Mpbs SFP port




2x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing)

Switching features

Transmission mode:storage and forward

System bandwidth:40Gbps (non-traffic jam)

Network media

10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)

100/1000BASE-TX: CAT5 or above shielded twisted pair(≤100m)

SFP port,transmission distance: 20Km,40Km,60Km,80Km,100Km

LEDs Power, network, fiber


Power supply

Input voltage:DC 9-52V

No-load power:5W

Reverse connection:support


Working temperature:-40°~ 85°C

Storage temperature:-40°~ 85°C

Working humidity:10%~90%,non-condensing

Storage humidity:10%~95%,non-condensing


CE Mark ,commercial

CE/LVD EN60950

Mechanical information

Shell:Corrugated metal shell

Safety class:IP40

Dimension: 114 x 93 x 35mm

Mounting method:Din-rail mounting

Warranty Replacement within 1 year; 3 years repairing


1 year for commercial products and 3 years for industrial products. Technical support will be offered free.


Application of mini rugged switch


3 Port Compact Gigabit Ethernet Switch Hardened With Industrial Temp 24V 1


Our Advantages


  • Easy to customize: we support printing your logo/model name on the device even if it is an order for several pieces.
  • Real-time demonstration: We will send actual product photos and testing videos to clients, our production lines contribute to good in-sales and after-sales services.
  • Fast dispatch, it usually takes 2~4 working days to release out the order by DHL/FedEx/UPS.
  • In stock: We got our own warehouse, for popular models, we have many in stock for fast delivery.

3 Port Compact Gigabit Ethernet Switch Hardened With Industrial Temp 24V 2

1 Q: Do you accept sample order?

A: Yes. Sample order to check our services and quality.


2 Q:Can I have any discounts?

A: Discounts will be given to repeat orders, regular clients and discount products.


3 Q:Tell me something about your packing.

A: It is neutral packing. If you have your own packing box, we support it.




We deliver goods by Express like DHL, UPS or FedEx.

It takes around 2~4 working days to deliver an order by DHL, UPS or FedEx.


The standard packing usually contains a main device, a warranty card and a user manual.

Packing box dimension for 1pc: 23*16.5*5.8cm

40pcs in a packing box of 67*33*47cm dimension.
