8 Optical SFP Slots 16 Port Gigabit Managed PoE Switch 10/100/1000M 802.3at

8 Optical SFP Slots 16 Port Gigabit Managed PoE Switch 10/100/1000M 802.3at
Features Gallery Product Description Request A Quote
Product Name: 1.25G Industrial POE Managed Network Switch
Port: 16
POE Budget: 240W
POE Standard: IEEE 802.3af, IEEE 802.3at
Weight: 0.45kg
Size: 15.8*11.5*6cm
High Light:

FCC Gigabit Managed PoE Switch


Gigabit Managed PoE Switch


802.3at Industrial Managed POE Switch

Basic Infomation
Place of Origin: Shenzhen, China
Brand Name: Olycom
Certification: CE RoHS FCC ISO9001
Model Number: IM-FP888GW V1
Payment & Shipping Terms
Packaging Details: 1pc in a carton, 0.9kg gross weight
Delivery Time: 3~7 working days
Payment Terms: L/C, PayPal
Supply Ability: 4000pcs/month
Product Description
16-Port Gigabit Smart Managed PoE Switch
Description of 16 port managed switch
  • Support power on POE IP cameras through the wireless access point (AP) of 5 categories of Ethernet cable. IEEE 802.3af/at power on to 1 ~ 8 RJ45 ports
  • 8 x 10/100/1000Mbps Auto-sensing RJ45 ports
  • 8 x 1000Mbps SFP fiber port
  • 4 KV Ethernet surge protection, adapt to a harsh outdoor environment Support Auto MDI/MDIX
  • Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Back pressure standard
  • IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant A store-and-forward switching mechanism
  • Operating environment temperature: -40 ° ~85 °C


Specification of Industrial POE switch
Product Name 10/100/1000Mbps Managed Industrial POE Fiber Switch (8F+8TP)

8x 1000Mpbs SFP port

SM: 1310nm/1550nm,20Km; 1490nm/1550nm, 40~120Km; MM: 1310nm, 2Km; 8x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing)

Standard IEEE 802.3, IEEE802.3U, IEEE802.3ab, IEEE802.3z, IEEE802.1d STP, IEEE802.1w RSTP, IEEE802.1s MSTP, ITU-T G.8023 EPR/Y.1344, IEEE802.1Q, IEEE802.1X, IEEE802.3ad, IEEE802.3x, IEEE802.3af, IEEE802.3at, IEEE802.1ad, IEEE802.1p, IEEE802.1ab, IEEE802.3az
Jumbo Frame 9.6KB
MAC Address Table Size 8K
Switching features Transmission mode: storage and forward System bandwidth: 56Gbps (non-traffic jam)
Network media

10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)

100/1000BASE-TX: CAT5 or above shielded twisted pair(≤100m)

SFP port,transmission distance: 20Km,40Km,60Km,80Km,100Km

LEDs Power, network, fiber
Power supply

POE power supply input voltage: 48V (max 52V),

Single PoE power supply output power: 15.4W (port 1~8) (802.3at standards required special instructions)

Environment Working Temp: -40°~ 85°C ; Storage Temp: -40°~ 85°C;Working humidity: 10%~90%, non-condensing; Storage humidity: 10%~95%, non-condensing
Industry Standards

EMI: FCC Part 15 Subpart B Class A,EN 55022 Class A

EMS: EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3, EN 61000-4-4

(EFT) Level 3, EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3, EN

61000-4-8; Traffic Control: NEMA-TS2; Vibration: IEC 60068-2-6; Freefall:

IEC 60068-2-32; Shock: IEC 60068-2-27; Rail Traffic: EN 50121-4

Safety CE Mark ,commercial ; CE/LVD EN60950
Mechanical information

Shell: Corrugated metal shell; Safety class: IP40

Dimension: 158 x 115 x 60mm;

Mounting method: Din-rail mounting

Warranty Replacement within 1 year; 3 years repairing


Management Software


8 Optical SFP Slots 16 Port Gigabit Managed PoE Switch 10/100/1000M 802.3at 0
  1. Support software upgrade via TFTP and HTTP, firmware redundancy prevents upgrade failing
  2. Support DHCP client/Relay/Snooping/Snooping option 82/Relay option 82
  3. Support RMON, MIB II, mirror image, event log, DNS, NTP/SNTP, IEEE802.1ab LLDP
  4. Support IPV6 Telnet server /ICMP v6, SNMP, HTTP, SSH/SSL, NTP/SNTP,TFTP, QoS, ACL
  5. Support IEEE802.3az EEE (Energy Efficient Ethernet) Management, optimize power consumption
  6. Support STP, RSTP, MSTP, ITU-T G.8032 Ethernet Protection Ring(EPR)
  7. Support IGMP/MLD snooping V1/V2/V3, IGMP filtrating/ modulating, IGMP searching
  8. Support IGMP agent report, MLD snooping
  9. Safety: based on port and Mac IEEE802.1X, RADIUS, ACL, TACACS+,HTTP/HTTPS, SSL/SSH v2
  10. Support Cisco® like CLI, Web management, SNMP v1/v2c/v3, Telnet
Application Diagram
8 Optical SFP Slots 16 Port Gigabit Managed PoE Switch 10/100/1000M 802.3at 1
