Gigabit 30W 60W PoE Switch Extender Industrial Grade SFP Fiber Switch Unmanaged DC48V

1pc
MOQ
Negotiable
Price
Gigabit 30W 60W PoE Switch Extender Industrial Grade SFP Fiber Switch Unmanaged DC48V
Features Gallery Product Description Ratings & Review Request A Quote
Features
Specifications
Product Name: Mini Rugged Gigabit POE Fiber Switch
Port: 3
Weight: 350g Net Weight
Voltage: DC48V
POE Budget: 60W
POE Standard: 15.4W/30W
Highlight:

Gigabit PoE Switch Extender

,

60W PoE Switch Extender

,

DC48V Industrial Unmanaged POE Switch
Basic Infomation
Place of Origin: Shenzhen, China
Brand Name: Olycom
Certification: ISO9001 CE RoHS FCC
Model Number: IM-FP122GE
Document: OLYCOM Industrial Networkin...25.pdf
Payment & Shipping Terms
Packaging Details: 1pc in a packing box, 0.45kg gross weight
Delivery Time: 3~6 working days
Payment Terms: T/T, PayPal
Supply Ability: 300pcs/week
Product Description
SFP optical fiber Gigabit Unmanaged PoE switch

Key Features of 60W POE Switch



  1. 2x 10/100/1000Mbps Auto-sensing RJ45 ports
  2. 1x 100/1000Mbps SFP fiber port
  3. Support Auto MDI/MDIX
  4. IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant
  5. Max power to 15.4W under af standard, 30W under at standard to each PoE port, 60W Max POE budget
  6. A store-and-forward switching mechanism
  7. Operating environment temperature: -40°C~75°C
  8. Meet IP40 protection degree and EMC industrial grade requirements
  9. DIN rail or wall installation
  10. Support power on POE IP cameras through the wireless access point (AP) of 5 categories of Ethernet cable



Technical Information of Rugged Fiber Switch



Product Name 10/100/1000Mbps Industrial POE Fiber Switch (1F+2TP)
Port

1x 100/1000Mpbs SFP port

SM:1310nm/1550nm, 20Km; 1490nm/1550nm,40~120Km

MM:1310nm, 2Km; 850nm, 500-meter

2x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing)
Switching features

Transmission mode: storage and forward

System bandwidth:6Gbps (non-traffic jam)
Network media

10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)

100/1000BASE-TX: CAT5 or above shielded twisted pair(≤100m)

SFP port,transmission distance: 20Km,40Km,60Km,80Km,100Km
LEDs

PWR: Power

Fiber: FX1

Copper orange: PoE indicator

On: PoE is working

Off :PoE is not working or this is Non-PoE device

Copper green: Link/Act indicator

On: transmission is normal

Off :transmission is NOT normal
Power supply

POE power supply input voltage: 48V (max 52V)

Single PoE power supply output power: 30W (port 1~2)
Total budget: 60W

PoE output voltage: 48V
Environment

Working temperature: -40～75°C

Storage temperature: -40～85°C

Working humidity: 10%～90%, non-condensing

Storage humidity: 10%～95%, non-condensing
Industry Standards

EMI: FCC Part 15 Subpart B Class A, EN 55022 Class A

EMS: EN 61000-4-2 (ESD) Level 3 ,EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3, EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3 ,EN 61000-4-8

Traffic Control :NEMA-TS2

Vibration :IEC 60068-2-6

Freefall:IEC 60068-2-32

Shock: IEC 60068-2-27

Rail Traffic:EN 50121-4
Safety

CE Mark , commercial

CE/LVD EN60950
Mechanical information

Shell: Corrugated metal shell

Safety class :IP40

Dimension: 113.8 x 93 x 34.9mm

Mounting method:Din-rail mounting
Warranty Replacement within 1 year; 3 years repairing



Packing Box Information





1pc switch

1pc user manual



Remark

Accessories(DIN rail bracket, optical module, power supply, patchcord, network cable etc.)are NOT included in the packing box

Pplease prepare it by yourself or purchase a whole set from us



Shipping box information

Product size: 11.4*9.3*3.5cm

Inner box size: 23*16.5*5.8cm

Product weight: 0.35Kg

Packing weight: 0.45Kg



Master box size: 67*33*47cm

Packing quantity: 40Pcs

Packing weight: 20Kg





Gigabit 30W 60W PoE Switch Extender Industrial Grade SFP Fiber Switch Unmanaged DC48V 0
