Multi-functional Video Data Ethernet over Fiber Media Converter
Introduction of video media converter
Features of analog video fiber converter
Specification of CCTV video converter
Single mode (9/125um) 20Km to 80Km
Multimode (50/125um) 1Km, ( 62.5/125um) 500m
|Impedance/Voltage||BNC 75Ω (unbalanced) / 2.0Vp-p|
|Differential Gain||< ±1%|
|Differential Phase||< ±1|
|S/N ratio||>60dB(weighting)(8 bit)|
|Data Protocol||RS232, RS422, RS485, Manchester, BIPHASE data|
|Work Mode||Full duplex / half duplex, autosensing|
|Network Speed||10/100Mbps, autosensing|
|Chassis and Cards|
|Chassis Slots Quantity||18 slots|
|Compatibility(with cards)||1~4ch cards(18pcs); 8ch cards(9pcs)|
|Flexibility||Supports mixed installation of different configurations|
In 4ch PCB(153x100x10mm) or 8ch PCB size (153x100x25mm)
configurations which require larger size can’t be used with this system
|Electrical. Environmental. Mechanical|
|Operating Voltage||Standalone:220VAC to 5V/12VDC, Rack: dual 220V/-48V AC, card: powered by chassis|
|Dimension And Weight||Standalone and card: depends on different configurations, Chassis: 19”3U|
Application of optical video converter
1 Q: What is your lead time?
A:It usually takes 2~4 working days to produce and then will send goods.
2 Q: How will you send my goods?
A: We will send the goods by DHL, TNT, UPS or FEDEX, please check the delivery details by the tracking number.
3 Q: Please tell me something about your MOQ
A: Our MOQ is 1 Pcs/Pair based on USD or EUR terms.
