Olycom 4-Port PoE Switch Fast Ethernet SFP Fiber Industrial Level 120W Budget Outdoor Use logo

Olycom 4-Port PoE Switch Fast Ethernet SFP Fiber Industrial Level 120W Budget Outdoor Use

1pc
MOQ
Negotiable
Price
Olycom 4-Port PoE Switch Fast Ethernet SFP Fiber Industrial Level 120W Budget Outdoor Use
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Industrial PoE Switch 4 Port
Fiber: 2*100M SFP Slots
Fiber Distance: Ideal For SM/MM Optical Modules
PoE Budget: 120W
PoE Distance: 100-meter
Customization: Support
Highlight:

Din Mount Poe Switch 1000 Mbps 4 Port

,

Two SFP IP Camera Poe Switch

,

Two SFP Switch 1000 Mbps 4 Port

Basic Infomation
Place of Origin: Shenzhen, China
Brand Name: OLYCOM
Certification: CE, FCC, RoHS
Model Number: IM-FP244FE
Payment & Shipping Terms
Packaging Details: One unit device and one user manual are inside one box , sealed and well protected.
Delivery Time: 3-5 working days
Payment Terms: T/T, Paypal
Supply Ability: 2000 units per month
Product Description

Olycom CCTV 120W PoE Fiber Switch 4 Port



Key Feature of 4 Port PoE Switch



  • Supply active PoE(DC48V) to PoE IP cameras, WAPs etc. through Cat5 or above copper cable
  • 2x100Mbps Auto-sensing SFP fiber ports
  • 4x10/100Mbps Auto-sensing RJ45, IEEE 802.3af/at power on to 1~ 4 ports
  • Detect the PoE modes(Non-PoE, 802.3af/at compliant) of connected electrical equipment
  • 6KV Ethernet surge protection, adapt to a harsh outdoor environment
  • Support Auto MDI/MDIX
  • Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Back pressure standard
  • IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant
  • DIN rail or Wall installation
  • Power range up to 100 meters
  • Comply with FCC and CE standards
  • A store-and-forward switching mechanism
  • Operating environment temperature: -40°C~75°C



It is an ideal solution for IP Surveillance, wind, electricity, subway PIS, assembly automation, power SCADA, sewage treatment, metallurgy, intelligent transportation, rail transportation, military and other industries



Technical Data of Industrial PoE Switch



Product Name 10/100Mbps Industrial PoE Fiber Switch(2F+4TP)
Model No. IM-FP244FE
Port

2x100M SFP Fiber

SM: 1310nm/1550nm, 20Km; 1490nm/1550nm, 40~120Km

MM: 1310nm, 2Km; 850nm, 500-meter

4x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing)

1x6-PIN Power Terminal Block

Protocol

IEEE 802.3(10Base-T)

IEEE 802.3u(100Base-TX)

IEEE 802.3af 15.4W(PoE)

IEEE 802.3at 30W(PoE+)

Switching Features

Transmission mode: storage and forward

Forwarding delay: <10us

System bandwidth: 1.2Gbps (non-traffic jam)

MAC: 4K

Packet buffer size: 1.75Mb

Network Media

10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)

100BASE-TX: CAT5 or above shielded twisted pair(≤100m)

LEDs

Power, Fiber, Network, PoE

PWR: Power



Fiber: FX1, FX2

On: transmission is normal

Off: transmission is NOT normal(faulty optical module or disconnected)



Copper orange: PoE indicator

On: PoE is working

Off: PoE is not working or this is Non-PoE device



Copper green: Speed indicator

On: transmission speed is 1000Mbps

Blinking: in transmission

Off: Disconnected or working speed is 10/100Mbps

Power Consumption Full loading without PoE≤5W
Power Supply

PoE power supply input voltage: 48V (max 52V)

Single PoE power supply output power: 30W (port 1~4)
Total budget: 120W

PoE output voltage: 48V

Reverse connection: support

PoE Wiring 1/2 (V+), 3/6 (V-)
Environment

Working temperature: -40°C~75°C

Storage temperature: -40°C~85°C

Working humidity: 10%~90%, non-condensing

Storage humidity: 10%~95%, non-condensing

Industry Standards

ESD: IEC61000-4-2, ±15KV air, ±6KV contact

EFT: IEC61000-4-4, General ±6KV

Surge: IEC61000-4-5, Differential ±2KV, Common±6KV

Certification

CE-EMC: EN 55032:2015+AC: 2016+A1:2020+A11: 2020

EN 55035:2017+A11: 2020/EN IEC 61000-3-2:2019/A1: 2021

EN 61000-3-3: 2013/A2: 2021/AC:2022

CE-LVD: EN IEC 62368-1: 2020+A11:2020

FCC: 47 CFR FCC Part 15 Subpart B(Class B) ANSI C63.4: 2014

Mechanical information

Shell: Corrugated metal shell, IP40 grade level

Dimension: 114*93*35mm

Mounting method: Din-rail/Wall mounting

Weight: 0.35Kg/0.45Kg(Net/Gross)

Warranty 3 years, lifetime technical support



Olycom 4-Port PoE Switch Fast Ethernet SFP Fiber Industrial Level 120W Budget Outdoor Use 0



Packing List



1pc switch

1pc user manual



Remark

Accessories(DIN rail bracket, optical module, power supply, patchcord, network cable etc.)are NOT included in the packing box, please prepare it by yourself or purchase a whole set from us



Shipping box information

Product size: 11.4*9.3*3.5cm

Inner box size: 23*16.5*5.8cm

Product weight: 0.35Kg

Packing weight: 0.45Kg

Master box size: 67*33*47cm

Packing quantity: 40Pcs

Packing weight: 20Kg



Accessories



Industrial Optical Module
OSPL1E06D-85 100BASE-FX(850nm)
OSPL1E06D 100BASE-FX
OSPL1E20D 100BASE-LX
OSPL1E40D 100BASE-EX
OSBL1E20D-35 100BASE-BX-U(TX 1310 RX1550)
OSBL1E20D-53 100BASE-BX-D(TX 1550 RX1310)
Industrial DIN Power Supply
IM-DAC220/DC12V1.67A AC220V to DC12V1.67A, -30℃~70℃
IM-DAC220/DC24V1A AC220V to DC24V1A, -30℃~70℃


Application of Fast Ethernet Fiber Switch


Olycom 4-Port PoE Switch Fast Ethernet SFP Fiber Industrial Level 120W Budget Outdoor Use 1



FAQ



What chip is it based?

Olycom: Realtek



Can I customize it?

Olycom: Yes

We support OEM services like logo, model name, label, PVC mask and product parts(mounting kit, power terminal block etc.)



Do you have any certification?

Yes, our company is ISO9001 certified.

We have CE/FCC/RoHS/E-mark/CCC certificates for our models.



What does the label look like?

There will be 2 copies for each piece of manufactured product. One is attached on the device, the other is on the packing box.

It is available in different languages and contents, so you can add your logo or model name in it.



Do you support OEM&ODM?

Yes, this is our competitive advantage.

There is a detailed introduction in the below link.

https://www.industrialnetworkswitch.com/factory.html



What incoterms do you support?

We are an EXW factory, EXW term is our focus.

Sometimes we do FOB/CIF for bulk orders, this depends on cases. Please talk with us for more information.



Do you attend some exhibitions?

Yes, we regularly attend IFSEC UK, MIPS RUSSIA, Security ESSEN GERMANY and ISC West USA.

Sometimes we are an exhibitor for some small shows like Mitec Malaysia, Secon Korea and Intersec Saudi Arabia.

Each time, we took many photos for displaying and record, please let us know if you need to check.





Olycom 4-Port PoE Switch Fast Ethernet SFP Fiber Industrial Level 120W Budget Outdoor Use 2



Olycom 4-Port PoE Switch Fast Ethernet SFP Fiber Industrial Level 120W Budget Outdoor Use 3
