Home /Products/Industrial Network Switch/5 Port Industrial Network Switch Hub 10/100Mbps SC Connector Unmanaged Realtek Based

5 Port Industrial Network Switch Hub 10/100Mbps SC Connector Unmanaged Realtek Based

1pc
MOQ
Negotiable
Price
5 Port Industrial Network Switch Hub 10/100Mbps SC Connector Unmanaged Realtek Based
Features Gallery Product Description Ratings & Review Request A Quote
Features
Specifications
Product Name: 10/100Mbps 5 Port Ethernet Switch Hub
Fiber Type: SC Single Fiber
Distance: 20/40/60/80/100km
Ethernet Port: 4* RJ45 Ports
Fiber Port: 1* SC Port
Feature: Unmanaged, Non-PoE
Highlight:

5 Port Industrial Network Switch 100Mbps

,

Industrial Network Switch Auto MDI

,

industrial switch hub Auto MDI
Basic Infomation
Place of Origin: Shenzhen, China
Brand Name: OLYCOM
Certification: CE, FCC, RoHS
Model Number: IM-FS140FE/SC
Document: OLYCOM Industrial Networkin...24.pdf
Payment & Shipping Terms
Packaging Details: One unit device and one user manual are inside one box , sealed and well protected.
Delivery Time: 3-5 days
Payment Terms: T/T, Paypal
Supply Ability: 2000 units per month
Product Description

10/100Mbps 5 Port Unmanaged Fiber Switch



Introduction of 5 Port Ethernet Switch


IM-FS140FE series is the 10/100 Mbps industrial fiber switch.

  • operating temperature -40 ℃ to + 75 ℃
  • support wide voltage dual power input
  • meet IP40 protection degree and EMC industrial grade requirements
  • DIN rail installation
  • pass through dangerous environmental certification
  • comply with FCC and CE standards

The reliable industrial grade design could ensure continuous and stable operation of the automation system.

Key Features of Industrial Fiber Switch



  • 4 x 10/100Mbps Auto-sensing RJ45 ports
  • 1 x 100Mbps SFP fiber port
  • 6KV Ethernet surge protection, adapt to a harsh outdoor environment
  • Support Auto MDI/MDIX
  • Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Backpressure standard
  • IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant
  • A store-and-forward switching mechanism
  • Operating environment temperature: -40 ° ~75 ° c



Specification of Unmanaged Network Switch



Product Name 10/100Mbps 5 Port Ethernet Switch Hub
Model No. IM-FS140FE
Port

1 x 100Mpbs port
SM: 1310nm/1550nm, 20Km; 1490nm/1550nm, 40~120Km
MM: 1310nm, 2Km
4x10/100M UTP RJ45(Support MDI/MDIX auto-sensing)
Switching features

Transmission mode: storage and forward
System bandwidth: 0.4Gbps (non-traffic jam)

DRAM size: 128M
Flash size: 16M
Packet buffer size: 4Mb
Network media

10BASE-T: CAT3, CAT4, CAT5 unshielded twisted pair(≤100m)
100BASE-TX: CAT5 or above shielded twisted pair(≤100m)
SC port,transmission distance: 20Km,40Km,60Km,80Km,100Km
LEDs Power, network, fiber
Power supply

Input voltage: DC 12-52V
No-load power:5W
Reverse connection: support
Environment

Working temperature:-40°～ 75°C
Storage temperature:-40°～ 85°C
Working humidity:10%～90%,non-condensing
Storage humidity:10%～95%,non-condensing
Industry Standards

EMI: FCC Part 15 Subpart B Class A, EN 55022 Class A
EMS: EN 61000-4-2 (ESD) Level 3, EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3, EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3, EN 61000-4-8
Traffic Control: NEMA-TS2
Vibration: IEC 60068-2-6
Freefall: IEC 60068-2-32
Shock: IEC 60068-2-27
Rail Traffic: EN 50121-4
Safety

CE Mark, commercial
CE/LVD EN60950
Mechanical information

Shell: Corrugated metal shell
Safety class: IP40
Dimension: 113.8 x 93 x 34.9mm
Mounting method: Din-rail mounting
Warranty 3 years



Packaging & Delivery



Selling Units: Single item

Single packaging size: 22*16*6cm

Single gross weight: 0.45kg

Package type: One product and one user manual are inside one box

Lead Time: 3-5days and will change according to different quantity


Application


5 Port Industrial Network Switch Hub 10/100Mbps SC Connector Unmanaged Realtek Based 0

5 Port Industrial Network Switch Hub 10/100Mbps SC Connector Unmanaged Realtek Based 1
