40Gbps Industrial Unmanaged POE Switch 10/100Base SFP Fiber Ports

1
MOQ
Negotiable
Price
40Gbps Industrial Unmanaged POE Switch 10/100Base SFP Fiber Ports
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: PoE Function Industrial Network Switch
Rate: 10/100M
SFP Ports: 4
Rj45 Ports: 2
Bandwidth: 40Gbps
POE Standard: 15.4W/30W
High Light:

40Gbps Industrial Unmanaged POE Switch

,

40Gbps poe switch with fiber port

,

Industrial Unmanaged POE Switch 10/100Base

Basic Infomation
Place of Origin: Shenzhen, China
Brand Name: OLYCOM
Certification: CE, FCC, RoHS
Model Number: IM-FP244FE
Payment & Shipping Terms
Packaging Details: One unit device and one user manual are inside one box , sealed and well protected.
Delivery Time: 3-5 days
Payment Terms: Western Union, T/T, Paypal
Supply Ability: 6000 per month
Product Description

PoE Function Industrial Network Switch 10/100Base SFP Fiber Ports



Introduction

IM-FP244FE is the 10/100 Mbps industrial POE fiber switch, comply with IEEE802.3af/at, power on POE IP cameras through the Ethernet cable, simple construction, power range up to 100 meters, operating temperature-40 ℃ to + 85 ℃, meet IP44 protection degree and EMC industrial grade requirements, DIN rail installation, pass through dangerous environmental certification and comply with FCC and CE standards. The reliable industrial grade design could ensure continuous and stable operation of the automation system.



Key Features

  1. Support power on POE IP cameras through the wireless access point (AP) of 5 categories of Ethernet cable.
  2. IEEE 802.3af power on to 1 ~ 4 RJ45 ports
  3. 4 x 10/100Mbps Auto-sensing RJ45 ports
  4. 2 x 100Mbps SFP fiber ports
  5. 4 KV Ethernet surge protection, adapt to a harsh outdoor environment
  6. Support Auto MDI/MDIX
  7. Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Back pressure standard
  8. IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant
  9. Max power to15.4W under af standard, 30W under at standard to each PoE port
  10. Detect the PoE models of electrical equipments.
  11. A store-and-forward switching mechanism
  12. Operating environment temperature:-40 ° ~85 ° c



Packaging & Delivery

  1. One product, one warranty card, and one user manual are in one box.
  2. 20pcs boxes are in one carton. (67*33*47cm)
  3. Port: Shenzhen
  4. Lead Time: 3-5days and will change according to different quantity



Quality Control

  • All the products we offer are brand new with new components and parts, and we absolutely never use old and refurbished materials.
  • Every production process has a special person to test to ensure quality
  • Every product must be tested before shipping to our customers. The quality is attached to great importance during the whole production process.
  • All products have passed CE, FCC, ROHS, and other certifications



  1. Specification



Product Name PoE Function Industrial Network Switch
Model No. IM-FP244FE
Port

2 x 100Mpbs SFP ports

SM:1310nm/1550nm,20Km

1490nm/1550nm,40~120Km

MM:1310nm,2Km

4x10/100M UTP RJ45(Support MDI/MDIX auto-sensing)

Switching features

Transmission mode: storage and forward

System bandwidth:40Gbps (non-traffic jam)

Network media

10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)

100BASE-TX: CAT5 or above shielded twisted pair(≤100m)

SFP port,transmission distance: 20Km,40Km,60Km,80Km,100Km

LEDs Power, network, fiber
Power supply

POE power supply input voltage: 48V (max 52V),

Single PoE power supply output power: 15.4W (port 1~4)

(802.3at standards required special instructions)

Environment

Working temperature:-40°~ 85°C

Storage temperature:-40°~ 85°C

Working humidity:10%~90%,non-condensing

Storage humidity:10%~95%,non-condensing

Industry Standards

EMI: FCC Part 15 Subpart B Class A, EN 55022 Class A

EMS:EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3,EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3,EN 61000-4-8

Traffic Control: NEMA-TS2

Vibration:IEC 60068-2-6

Freefall:IEC 60068-2-32

Shock:IEC 60068-2-27

Rail Traffic: EN 50121-4

Safety

CE Mark , commercial

CE/LVD EN60950

Mechanical information

Shell: Corrugated metal shell

Safety class: IP44

Dimension:158 x 114.8 x 60mm

Mounting method: Din-rail mounting

Warranty Replacement within 1 year; 5 years repairing



Application

40Gbps Industrial Unmanaged POE Switch 10/100Base SFP Fiber Ports 0
