Gigabit Switch 4 Port Unmanaged Network Switch Metal Plug And Play
Introduction of Gigabit Switch
Gigabit Switch 4 port is the 10/100/1000 Mbps industrial fiber switch, operating temperature -40 ℃ to + 75 ℃, support wide voltage dual power input, meet IP44 protection degree and EMC industrial grade requirements, DIN rail installation, pass through dangerous environmental certification and comply with FCC and CE standards. The reliable industrial grade design could ensure continuous and stable operation of the automation system.
Key Features of Gigabit Switch
Specification of Gigabit Switch
| Model No. | IM-FS440GE |
| Port |
4 x 1000Mpbs SFP ports SM:1310nm/1550nm,20Km 1490nm/1550nm,40~120Km MM:1310nm,2Km 4x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing) |
| Switching features |
Transmission mode: storage and forward System bandwidth:40Gbps (non-traffic jam) |
| Network media |
10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m) 100/1000BASE-TX: CAT5 or above shielded twisted pair(≤100m) SFP port, transmission distance: 20Km,40Km,60Km,80Km,100Km |
| LEDs | Power, network, fiber |
| Power supply |
Input voltage: DC 12-52V No-load power:5W Reverse connection: support |
| Environment |
Working temperature:-40°～ 75°C Storage temperature:-40°～ 85°C Working humidity:10%～90%,non-condensing Storage humidity:10%～95%,non-condensing |
| Industry Standards |
EMI: FCC Part 15 Subpart B Class A, EN 55022 Class A EMS:EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3,EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3,EN 61000-4-8 Traffic Control: NEMA-TS2 Vibration: IEC 60068-2-6 Freefall: IEC 60068-2-32 Shock: IEC 60068-2-27 Rail Traffic: EN 50121-4 |
| Safety |
CE Mark, commercial CE/LVD EN60950 |
| Mechanical information |
Shell: Corrugated metal shell Safety class: IP40 Dimension:158 x 114.8 x 60mm Mounting method: Din-rail mounting |
| Warranty | 3 years |
Packaging & Delivery of Gigabit Switch
1. One product and one user manual are inside one box.
2. 20pcs boxes are in one carton (67*33*47cm)
3. Lead Time:
| Quantity(Pieces) | 1-100 | >100 |
| Time(Days) | 3 | Negotiable |
Application of Gigabit Switch
Photo of Gigabit Switch
