48V1A 2 Port Fiber Media Converter

1 pair
48V1A 2 Port Fiber Media Converter
Features Gallery Product Description Request A Quote
Product Name: Sinele Mode Fiber To Ethernet Converter
Fiber Port: SC, ST/FC Optional
Wavelength: 1310nm/1550nm, WDM
Weight: Gross Weight: 0.5kg
Buffer Size: 1M
PoE Pin Assignment: 1/2 (V+),3/6 (V-)
Warranty: 1 Year
Size: 135mm(L) X 90mm(W) X 28mm(H)
High Light:

48V1A Ethernet To Fiber Converter


48V1A 2 port fiber media converter


FCC black 2 Port Fiber Media Converter

Basic Infomation
Place of Origin: Shenzhen, China
Brand Name: Olycom
Certification: CE RoHS FCC
Model Number: TA540-PSE-FE
Payment & Shipping Terms
Packaging Details: 1 piece in 1 carton. 0.5KG/pcs
Delivery Time: 3~7 working days
Payment Terms: T/T, Paypal
Supply Ability: 1200 pairs per week
Product Description

2 Port Sing Core SC 10 100 POE Optical Media Converter Rack Mountable 48V1A Black




Olycom 10/100Mbps Megabit PSE fiber to copper Ethernet converter provides you with


  1. IEEE 802.3af/at Power Sourcing Ethernet (PSE) functionality on the twisted pair port
  2. supplying both data and electric current to devices like IP security cameras and VoIP phones
  3. install Powered Devices (PD) anywhere around the LAN
  4. performs media conversion as well as providing electric current to the end-device at the remote site


Model: TA540-PSE-FE, we support your model


Key Features


  • 1 x 100Base-FX or SX fiber port
  • 1 x 10/100Base-TX port for data and power
  • IEEE802.3af/at compliant
  • External Power supply
  • Diagnostic and unit LEDs and PoE current indicator LEDs
  • Externalized DIP switch for convenient configuration




Standard IEEE802.3 (10BASE-T), IEEE802.3u 100BASE-TX/FX (Fast-Ethernet), IEEE802.3x (Flow Control), IEEE802.1q, IEEE802.1p QoS, IEEE802.1d Spanning Tree, IEEE802.3af /at PoE/PSE
10/100BASE-T STP or UTP Category 5/5e/6 cable (Max. 100m)
100BASE-FX 9/125um SMF (20km)
Conversion Mode / Delay Time Store-and-Forward < 10us, straight-through<0.9us
Flow control Full duplex-flow control, Half duplex-back pressure
RJ-45 Port Auto-MDI/MDIX
Fiber Connector SC standard, ST/FC optional
Wavelength 1310/1550nm
Input Voltage 48VDC/1A external power supply
Power Consumption <2.5W
PoE Pin Assignment 1/2 (V+),3/6 (V-)
PoE Output -48V, 0.54A, 25W



















MTBF 50,000 hours
BER <1/1000000000
MAC Address Table 1K
Buffer Size 1M
Operation Temperature 0℃~50℃
Storage Temperature -20℃~85℃
Storage Humidity 5%~90% non-condescending
Dimensions and Weight 135mm(L) x 90mm(W) x 28mm(H), Net weight : 0.3kg, Gross weight : 0.5kg
