1080P Compressed Hdmi Two Fiber Ports And Two USB Ports HDMI Video To Fiber Converter
Introduction of Fiber Converter
OLYCOM HDMI video optical converter compresses and converts 1080P HD video signal to network signal so that HD video signal could be transmitted long distance by network cable. HDMI video optical converter could be widely used in security systems, subway/railway advertising, mall advertising, building exhibition, digital signage, visual media teaching, digital KVM, and other fields.
Key Features of Fiber Converter
Specification of Fiber Converter
| Video Compress Format | M-JPEG: Compress 1080P@60HZ video signal to 50Mbps |
| Video Interface | HDMI: Support HDMI1.1/1.2/1.3, HDCP1.1/1.2, Compatible with DVI |
| Protocol | TCP/IP: Standard TCP/IP network protocol |
| Transmission Delay | 70ms: Direct transmission delay less than 70 ms. |
| Remote Control | UART, USB: RS232, USB |
| RJ-45 Port | Auto-MDI/MDIX |
| Video Resolution | VES & CEA-861: 640*480, 720*576, 800*600, 1024*600, 1024*768, 1152*864, 1280*600, 1280*720, 1280*768, 1280*800, 1280*960, 1280*1024, 1440*1050, 1440*900, 1600*900, 1660*1200, 1680*1050, 1920*1080 |
| Audio | Digital Audio: 32khz,44.1khz,48khz. |
| Fiber Port | SC(ST,FC optional) |
| Consumption | 12V1A/2A |
| Working Temperature | 0-70℃ |
| Dimension | 152.8mm*130mm*28.3mm |
Interface of Fiber Converter
| Name | Description |
| DC | 12V1A |
| F/W | Reset Button |
| RJ45 | Normal network interface, connect with switch or connect transmitter and receiver directly |
| HDMI/DVI | Transmitter: HD video input port / Receiver: HD video output port |
| LED | PWR；Video status indicator；Network connection indicator；Fiber indicator |
Application of Fiber Converter
Ordering Details of Fiber Converter
| OM615-CH2FKM-T/R | Compressed HDMI Video Optical Converter, two fiber ports, two USB ports |
| OM615-CH2F-T/R | Compressed HDMI Video Optical Converter, two fiber ports |
| OM615-CH1RKM-T/R | Compressed HDMI Extender, one RJ45 ports, two USB ports |
| OM615-CH1R-T/R | Compressed HDMI Extender, one RJ45 port |
| OM615-CH2RKM-T/R | Compressed HDMI Extender, two RJ45 ports, two USB ports |
| OM615-CH2R-T/R | Compressed HDMI Extender, two RJ45 ports, |
| OM615-CH1R1FKM-T/R | Compressed HDMI Video Optical Converter, one RJ45 port,one fiber port, two USB ports |
| OM615-CH1R1F-T/R | Compressed HDMI Video Optical Converter, one RJ45 ports,one fiber ports |
| OM615-CH2R2FKM-T/R | Compressed HDMI Video Optical Converter, two RJ45 ports, two fiber ports, two USB ports |
| OM615-CH2R2F-T/R | Compressed HDMI Video Optical Converter, two RJ45 ports,two fiber ports |
| OM615-CH1FKM-T/R | Compressed HDMI Video Optical Converter, one fiber ports, two USB ports |
| OM615-CH1F-T/R | Compressed HDMI Video Optical Converter, one fiber ports |
