5-port Industrial Network Switch E-mark Ethernet Switch With 4 KV Surge Protection

1pc
MOQ
Negotiable
Price
5-port Industrial Network Switch E-mark Ethernet Switch With 4 KV Surge Protection
Features Gallery Product Description Request A Quote
Features
Specifications
Transmission Mode: Storage And Forward
System Bandwidth: 40Gbps (non-traffic Jam)
LEDs: Power, Network
Input Voltage: DC 9-52V
Rail Traffic: EN 50121-4
Certification: E-Mark Certification, CE, FCC, ROHS
Warranty: 3 Years
High Light:

5-port Industrial Network Switch

,

E-mark Industrial Network Switch

Basic Infomation
Place of Origin: Shenzhen, China
Brand Name: Olycom
Certification: CE RoHS FCC ISO9001 E-mark
Model Number: IM-FS050GE
Payment & Shipping Terms
Packaging Details: 1pc in a box, 0.45kg gross weight
Delivery Time: 4~7 working days
Payment Terms: T/T, PayPal
Supply Ability: 3000pcs/month
Product Description

Full Gigabit E-mark Industrial Ethernet 5-port Switch



Key Features of E-mark Ethernet Switch



  • 5 x 10/100/1000Mbps Auto-sensing RJ45 ports
  • 4 KV Ethernet surge protection, adapt to a harsh outdoor environment Support Auto MDI/MDIX
  • Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Back pressure standard
  • IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant A store-and-forward switching mechanism
  • Operating environment temperature: -40 ° ~75 ° c



Application of E-Mark Certified Ethernet Switch

Introducing our IM-FS050GE series - the ultimate 10/100/1000 Mbps industrial network switch. Boasting a simple yet robust construction, it can handle power range up to 100 meters and can operate flawlessly in extreme temperature from -40 ℃ to + 75 ℃. With its IP40 protection degree and EMC industrial grade requirements, it's the perfect choice for industrial applications that require reliable network connectivity. Plus, it's easy to install with DIN rail installation, and it has passed dangerous environmental certification, and complies with FCC and CE standards, making it a top choice for your automation system. Trust in our industrial-grade design for continuous and stable network operation, even in the toughest of environments.



5-port Industrial Network Switch E-mark Ethernet Switch With 4 KV Surge Protection 0



Dimension of 5-port Gigabit switch



5-port Industrial Network Switch E-mark Ethernet Switch With 4 KV Surge Protection 1



Packing box of Din rail unmanaged switch



5-port Industrial Network Switch E-mark Ethernet Switch With 4 KV Surge Protection 2

Production steps



  1. Welding: Weld the necessary components
  2. Cleaning: To avoid any possible dysfunction due to dust or scraps on the PCB boards.
  3. Assembling: Builds up components of a product, like panels, screws, PCB boards.
  4. Testing: To make sure the product is basically working fine after assembling
  5. Aging: To check if the product can work smoothly for long time without any minors such as LED indicators, voltage. This will usually last for 24 to 48 hours.
  6. Testing: To test if the product can process data or video signals correctly. Any data loss? Transmission rate correct? Any data packet failure? Such questions would be verified in this procedure.
  7. QC testing: This is the third and also last check of product quality. If it goes good, our packing staff will pack it up according to customer requirements and attach to the packing box a product label.
  8. When all above is done, the product will go to market.
