Four RJ45 Port Industrial Network Switch Fiber Optic 6 Port Full Duplex Half Duplex
1
MOQ
Negotiable
Price
Four RJ45 Port Industrial Network Switch Fiber Optic 6 Port Full Duplex Half Duplex
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Shenzhen, China
Brand Name: OLYCOM
Certification: CE, FCC, RoHS
Model Number: IM-FS240FE
High Light:

Four RJ45 Port Industrial Network Switch

,

Full Duplex Half Duplex Industrial Network Switch

,

Four RJ45 Port Switch Fiber Optic 6 Port

Payment & Shipping Terms
Packaging Details: One unit device and one user manual are inside one box , sealed and well protected.
Delivery Time: 3-5 days
Payment Terms: Western Union, T/T, Paypal, D/P, D/A, L/C, MoneyGram
Supply Ability: 600 per month
Specifications
Product Name: 10/100Mbps Industrial Network Ethernet Switch
Communication Mode: Full-Duplex & Half-Duplex
Condition: 100% Original Brand
Working Temperature: -45~85℃
Ports: 6
Warranty: 3 Years
Product Description

10/100Mbps Industrial Network Ethernet Switch Two SFP Fiber Port And Four RJ45 Port

Introduction
IM-FS240FE is the 10/100 Mbps industrial fiber switch, operating temperature-40 ℃ to + 85 ℃, support wide voltage dual power input, meet IP40 protection degree and EMC industrial grade requirements, DIN rail installation, pass through dangerous environmental certification and comply with FCC and CE standards. The reliable industrial grade design could ensure continuous and stable operation of the automation system.


Key Features

  1. 4 x 10/100Mbps Auto-sensing RJ45 ports
  2. 2 x 100Mbps SFP fiber port
  3. 4 KV Ethernet surge protection, adapt to a harsh outdoor environment
  4. Support Auto MDI/MDIX
  5. Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Back pressure standard
  6. IEEE 802.3 10Base-T and IEEE 802.3u 1000Base-TX compliant
  7. A store-and-forward switching mechanism
  8. Operating environment temperature:-40 ° ~85 ° c



Industry Standards

  • EMI: FCC Part 15 Subpart B Class A, EN 55022 Class A
  • EMS: EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3,EN 61000-4-5 (Surge) Level 3,  EN 61000-4-6 (CS) Level 3,EN 61000-4-8
  • Traffic Control: NEMA-TS2
  • Vibration: IEC 60068-2-6
  • Freefall: IEC 60068-2-32
  • Shock: IEC 60068-2-27
  • Rail Traffic: EN 50121-4



Mechanical information

  1. Shell: Corrugated metal shell
  2. Safety class: IP40
  3. Dimension: 113.8 x 93 x 34.9mm
  4. Mounting method: Din-rail mounting



Specification

Product Name 10/100Mbps Industrial Fiber Switch (2F+4TP)
Model No. IM-FS240FE
Port

2 x 100Mpbs SFP ports
SM:1310nm/1550nm,20Km
1490nm/1550nm,40~120Km
MM:1310nm,2Km
4x10/100M UTP RJ45(Support MDI/MDIX auto-sensing)

Switching features

Transmission mode: storage and forward
System bandwidth:40Gbps (non-traffic jam)

Network media

10BASE-T: CAT3, CAT4, CAT5 unshielded twisted pair(≤100m)
100/1000BASE-TX: CAT5 or above shielded twisted pair(≤100m)
SFP port,transmission distance: 20Km,40Km,60Km,80Km,100Km

LEDs Power, network, fiber
Power supply

Input voltage:DC 9-52V
No-load power:5W
Reverse connection: support

Environment

Working temperature:-40°~ 85°C
Storage temperature:-40°~ 85°C
Working humidity:10%~90%,non-condensing
Storage humidity:10%~95%,non-condensing

Safety

CE Mark, commercial
CE/LVD EN60950

Warranty Replacement within 1year; 5 years repairing





FAQ

Q: How can we guarantee the quality?

A: Always a pre-production sample before mass production;
Always final Inspection before shipment;



Q: Why should you buy from us, not from other suppliers?

A:  Shenzhen Olycom Technology Co., Ltd. is a manufacturer of fiber optic since 2003. We have passed the HIGH-TECH and ISO9001. There are many domestic and abroad agents which help us to have a good market share.



Q: What services can we provide?

A: Accepted Delivery Terms: EXW;
Accepted Payment Currency:USD,EUR,JPY,CAD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,PayPal,Western Union;
Language Spoken:English,Chinese,Spanish,Russian


Application
Four RJ45 Port Industrial Network Switch Fiber Optic 6 Port Full Duplex Half Duplex 0




Four RJ45 Port Industrial Network Switch Fiber Optic 6 Port Full Duplex Half Duplex 1
