24 port gigabit DC12V8A 10G SFP L3 Managed Ethernet Fiber Switch
Introduction of 10/100/1000mbps managed switch
28 Port 10G Uplink 24* SFP Port Gigabit L3 Managed Ethernet Switch, support 24* 1000M SFP Ports, 8* 10/100/1000M adaptive Ethernet Ports(Combo), 4* 10G SFP Ports, 1* Console Port. Perfect security control strategy and CPU
protect policy improve fault tolerance and ensure stable operation of the network and load balancing of the interconnection；
The device supports automatic DoS attack defense and SNMP, IEEE 802.1, STP, RSTP, Link aggregation, and other functions. With advanced security functions and quality of service (QoS), it can be used as core layer, distribution layer ,and access layer switch with high density port and easy management, is an ideal choice for various business network applications.
Key features
Support 24* 10/100/1000M adaptive SFP Ports, 8* 10/100/1000M adaptive Ethernet Ports(Combo), 4* 10G SFP +Ports, 1* Console Port;
Support IEEE 802.1d, IEEE 802.1w, IEEE 802.1s, IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ae standard;
L3 Management, support DHCP Server, QoS, ACL control, support SNMP V1/V2/V3, IGMP Snooping v1/v2；
Support STP/RSTP/MSTP(ERPS), support loop detection and self-healing, support remote loopback monitoring and control (802.3ah OAM);
Support multiple VLAN division, MAC VLAN, Protocol VLAN, Private VLAN；
Support IP address + MAC address + VLAN + Port binding, DHCP Snooping, support IP source and DAI protection;
Support IPV4/IPV6, RIP v1/v2, OSPF v2.
Lightning protection: common mode 4KV, differential mode 2KV
Specification of 10/100/1000 POE Ethernet Switch
| I/O Interface | |
| Power | AC 100~240V 50/60Hz |
| Ethernet |
4* Gigabit PoE ports 2* Gigabit Ethernet ports |
| Hardware parameters | |
| Bandwidth | 12Gbps |
| Packet Forwarding Rate | 8.928Mpps |
| Package Cache | 1Mbit |
| Mac Address | 2K |
| Jumbo Frame | 9216bytes |
| Forwarding mode | Store Forward |
| Protocol Standard | |
| Network Protocol |
IEEE 802.3 IEEE 802.3u IEEE 802.3ab IEEE 802.3x |
| PoE Protocol |
IEEE802.3af (15.4 W) IEEE802.3at (30 W) |
| Network Media |
10Base-T : Cat3, 4, 5 or above UTP/STP(≤100m) 100Base-TX : Cat5 or aboveUTP/STP(≤100m) 1000Base-TX : Cat5 or aboveUTP/STP(≤100m) |
| Safety certification | CE, FCC, RoHS |
