    Product Details:

    Place of Origin: China
    Brand Name: Hengsion
    Certification: CE, FCC, ROHS
    Model Number: MIB05G

    Payment & Shipping Terms:

    Minimum Order Quantity: No less than 50 sets for one order.
    Price: Negotiation
    Packaging Details: Packing in individual boxes, then delivered with outer corrugated cartons.
    Delivery Time: 3-15 working days after prepayment (depending on the stock)
    Payment Terms: T/T at sight, LC, Western Union
    Supply Ability: 3000 sets per month
    Contact Now
    Detailed Product Description
    Installation: Din Rail Relative Humidity: 5~95%,non-condensing
    Weight: 0.55Kg File Transfer: Support Log Output, Configuration File Backup And Input
    Management Access: Support Console, Telnet Traffic Management: Port Traffic Monitoring And Fault Event Alarming
    High Light:

    managed industrial ethernet switch

    ,

    fully managed switch





    5 Port Managed Gigabit Ethernet Switch , Industrial Fast Ethernet Media Converter



    Introduction



    HENGSION Managed MIB05G industrial Ethernet switch provides 5*1000BaseT(X) fast Ethernet ports. No fan, low power consumption design; With complete security and QoS policies; Support VLAN division, port mirroring, and port rate limiting; Support broadcast storm suppression, flow control, and centralized management and configuration by WEB,CLI,SNMP; Din rail corrugated metal casing, meet IP40 protection grade; Dual redundant power input; Comply with CE, FCC and ROHS standards.



    Its wide operating temperature range and port surge protection design are ideal for application in large flow real-time outdoor environment, and are widely used in industrial automation control and surveillance occasions like campus, community, rail traffic, electric power control and so on.





    ◇ 5*1000Base T(X) fast Ethernet ports

    ◇ Wire speed forwarding capability of all ports make sure of non-blocking message forwarding.

    ◇ Support 802.1x authentication, VLAN, and broadcast storm suppression.

    ◇ Loop detection and Port+ IP+MAC binding.

    ◇ Port traffic monitoring and fault event alarming

    ◇ Support WEB visual interface, support SNMP management.

    ◇ Automatic MDI/MDI-X crossover for plug-and-play

    ◇ Dual redundant power input, with overload protection and power reverse polarity protection.

    ◇ Full-loaded operating temperature range -40 to 85℃.

    ◇ No fan, low power consumption design.

    ◇ Din rail corrugated metal casing, meet IP40 protection grade.

    ◇ Industrial Level-4 design.







    Specification



    Technology
    Standards IEEE 802.3,802.3u,802.3x, 802.3ab, 802.3z; IEEE802.1Q,802.1p,802.1D,802.1w,802.1s,802.1X,802.1ab
    Protocols Ring, MSTP, IGMP Snooping, GMRP,VLAN,PVLAN, Telnet, HTTP, HTTPS, RMON,SNMPv1/v2/v3,LLDP,SNTP,DHCP server,SSH,SSL,ACL,FTP,ARP,QoS
    Interface
    Gigabit Ethernet port 10/100/1000 Base-T(X) auto-adaptive RJ45
    Console port 3.81mm industrial terminal
    Power port 5.08mm industrial terminal
    Switching Features
    Processing Type Store & forward, wire speed switching
    Switching bandwidth 10Gbps
    Packet forwarding speed 8.9Mpps
    MAC Address 4K
    Buffer Memory 1Mb
    Priority Queue 4
    VLAN number 4K
    VLAN ID 1-4096
    Multicast groups 256
    Software Features
    VLAN 802.1Q,Vlan(4K), Port-based VLAN, Q-in-Q
    Storm Suppression Broadcast, multicast, and unknown unicast storm suppression
    Flow control IEEE802.3X negotiation, CAR function, rate limiting step 64K
    Multicast protocol IGMPv1/2/3 Snooping
    Port Management Support port mirroring, port isolation, port trunking
    DHCP Management Support DHCP Snooping, option 82
    QoS (Quality of Service) 802.1p; Support port default priority tags, at least 4 different priority queues per port
    Security features MAC address filtering, dynamic or static MAC address learning, Loop detection and Port+ IP+MAC binding
    Traffic Management Port traffic monitoring and fault event alarming
    Management SNMP v1/v2/v3, CLI,WEB
    Management Access Support Console, Telnet
    System Maintenance RMON,PDP Discovery Protocol(CDP compliant),AST
    File transfer Support Log output, configuration file backup and input
    LED Indicator for
    Power, Device running status, Ethernet port connection & running status, Fiber port connection & running status
    Power
    Input Voltage Range 9-36VDC / 9-36VAC redundant input
    Idle Consumption 0.2A@12VDC(Max)
    Full -load Consumption 0.4A@12VDC(Max)
    Connection 5.08mm industrial terminal
    Protection Overload Current Protection; Redundancy protection
    Mechanical
    Casing Strengthened corrugated metal casing
    Protection grade IP40
    Dimension(L*W*H) 150*128.5*37mm
    Installation Din Rail
    Weight 0.55Kg
    Environmental
    Operating Temperature -40℃~+85℃
    Storage Temperature -45℃~+85℃
    Relative Humidity 5~95%,non-condensing
    Industry Approvals
    EMI FCC Part 15,CISPR(EN55022) class A





    EMS

    EN61000-4-2(ESD), Level 4
    EN61000-4-3(RS),Level 3
    EN61000-4-4(EFT),Level 4
    EN61000-4-5(Surge),Level 4
    EN61000-4-6(CS),Level 3
    EN61000-4-8,Level 5
    Shock IEC 60068-2-27
    Free Fall IEC 60068-2-32
    Vibration IEC 60068-2-6
    Warranty
    Warranty Period 5 years







    Ordering Information



    Available Models Port Interface
    1000Base FX SFP (LC) 1000Base FX (SC/ST/FC) 10/100/1000Base T(X)
    MIB05G 0 0 5

    Optional Accessories (can be purchased separately)

    DR-30D12, Din-Rail power supply, 85-264VAC/120-370VDC@12VDC , -20 to 60℃ operating temperature

    GS-36D12, Power adaptor, 100-240VAC@12VDC, -20 to 50℃ operating temperature





    Package Checklist

    • Ethernet switch

    • Hardware installation guide(printed)

    • Warranty Card



    Dimension
