512Kb unmanaged gigabit switch No fan , 6 port ethernet switch with 2 fiber optic ports

512Kb unmanaged gigabit switch No fan , 6 port ethernet switch with 2 fiber optic ports

    • 512Kb unmanaged gigabit switch No fan , 6 port ethernet switch with 2 fiber optic ports
    • 512Kb unmanaged gigabit switch No fan , 6 port ethernet switch with 2 fiber optic ports
    • 512Kb unmanaged gigabit switch No fan , 6 port ethernet switch with 2 fiber optic ports
  • 512Kb unmanaged gigabit switch No fan , 6 port ethernet switch with 2 fiber optic ports

    Product Details:

    Place of Origin: China
    Brand Name: Hengsion
    Certification: CE, FCC, ROHS
    Model Number: ENI08S-6E-2F

    Payment & Shipping Terms:

    Minimum Order Quantity: No less than 50 sets for one order.
    Price: Negotiation
    Packaging Details: Packing in individual boxes, then delivered with outer corrugated cartons.
    Delivery Time: 3-15 working days after prepayment (depending on the stock)
    Payment Terms: T/T at sight, LC, Western Union
    Supply Ability: 3000 sets per month
    Contact Now
    Detailed Product Description
    Buffer Memory: 512Kb Switching Bandwidth: 1.6Gbps
    Idle Consumption: 0.37A@12VDC(Max) Installation: Wall Mount
    Full Duplex Flow: Support IEEE/802.3x Full Duplex Flow Control Polarity Protection: With Power Reverse Polarity Protection



    512Kb unmanaged gigabit switch No fan , 6 port ethernet switch with 2 fiber optic ports



    Introduction:



    HENGSION unmanaged ENI08S-6E-2F Ethernet switch provides 2*100Base FX fiber optic ports and 6*100BaseT(X) fast Ethernet ports.

    No fan, low power consumption design;

    Its wide operating temperature range and port surge protection design are ideal for application in large flow real-time outdoor environment, and are widely used for occasions including enterprise, intelligent building, cafe, community access or gathering etc., and for industries like finance, education and government etc.



    △ Wire speed forwarding capability of all ports make sure of non-blocking message forwarding.

    △ 6*100Base T(X) fast Ethernet ports & 2*100Base FX fiber optic ports

    △ Support IEEE/802.3x full duplex flow control and Backpressure half duplex flow control.

    △ Support full-loaded operating temperature range -30 to 75℃.

    △ Automatic MDI/MDI-X crossover for plug-and-play

    △ With power reverse polarity protection.

    △ Wall-mount installation







    Specification:



    Technology
    Standards IEEE 802.3,802.3u,802.3x
    Interface
    Megabit Ethernet port 10/100 Base-T(X) auto-adaptive RJ45
    Megabit Fiber port 100Base-FX port (SC by default, FC/ST optional)
    Power port 5.08mm industrial terminal
    Switching Features
    Processing Type Store & forward, wire speed switching
    Switching bandwidth 1.6Gbps
    Packet forwarding speed 1.2Mpps
    MAC Address 1K
    Buffer Memory 512Kb
    LED Indicator for
    Power, Ethernet port connection & running status, Fiber port connection & running status
    Power
    Input Voltage Range 12VDC
    Idle Consumption 0.37A@12VDC(Max)
    Full -load Consumption 0.69A@12VDC(Max)
    Connection 2 core 5.08mm industrial terminal
    Protection Overload current protection; Reverse polarity protection
    Mechanical
    Dimension(L*W*H) 160*115*43.5mm
    Installation Wall mount
    Weight 0.55Kg
    Environmental
    Operating Temperature -30℃~+75℃
    Storage Temperature -40℃~+85℃
    Relative Humidity 5~95%,non-condensing
    Warranty
    Warranty Period 2 years







    Ordering Information:



    Available Models Port Interface
    1000Base FX SFP 10/100/1000Base T(X) 100Base F(X) or SFP 100Base T(X)
    ENI08S-6E-2F 0 0 2 6



    Package Checklist:



    • Ethernet switch

    • Power adaptor

    • Hardware installation guide(printed)

    • Warranty Card



    Product Picture

    512Kb unmanaged gigabit switch No fan , 6 port ethernet switch with 2 fiber optic ports
