16 Gigabit PoE Ports High Power Poe Switch With IEEE802.3at Standard Ethernet Switch

16 Gigabit PoE Ports High Power Poe Switch With IEEE802.3at Standard Ethernet Switch

    • 16 Gigabit PoE Ports High Power Poe Switch With IEEE802.3at Standard Ethernet Switch
    • 16 Gigabit PoE Ports High Power Poe Switch With IEEE802.3at Standard Ethernet Switch
  • 16 Gigabit PoE Ports High Power Poe Switch With IEEE802.3at Standard Ethernet Switch

    Product Details:

    Place of Origin: China
    Brand Name: Hengsion
    Certification: ISO/FCC/RoSH/CE
    Model Number: MNB28G-16EGPT-M

    Payment & Shipping Terms:

    Minimum Order Quantity: 10 sets
    Price: $20-2000 / set
    Packaging Details: carton
    Delivery Time: 5-15 work days
    Payment Terms: T/T, Western Union, L/C, D/A, D/P, MoneyGram
    Supply Ability: 3000 sets / month
    Contact Now
    Detailed Product Description
    Storm Suppression: Broadcast, Multicast, And Unknown Unicast Storm Suppression Multicast Protocol: IGMPv1/2/3 Snooping
    DHCP Management: Support DHCP Snooping, Option 82
    High Light:

    poe powered network switch

    ,

    outdoor poe switch

    MNB28G-16EGPT-4G-M
    Managed 16*1000BaseT(X) POE(30w) Ethernet Switch

    16*1000Base T(X) POE Ethernet ports
    POE Ethernet ports fully compliant with IEEE802.3at standard provide up to 30 Watts per port.
    Support Ethernet redundant Ring protocol( recovery time≤20ms)
    Wire speed forwarding capability of all ports make sure of non-blocking message forwarding.
    Support 802.1x authentication, VLAN, and broadcast storm suppression.
    Loop detection and Port+ IP+MAC binding.
    Port traffic monitoring and fault event alarming
    Support WEB visual interface, support SNMP management.
    Automatic MDI/MDI-X crossover for plug-and-play
    Overload protection and power reverse polarity protection.
    Full-loaded operating temperature range -20 to 60℃.
    No fan, low power consumption design.
    19” 1U Rack Mount installation
    With inner 455w POE power supply

    Specification

    Technology
    Standards

    IEEE 802.3,802.3u,802.3x, 802.3ab, 802.3z; IEEE802.1Q,802.1p,802.1D,802.1w,802.1s,802.1X,802.1ab
    IEEE802.3at.

    ProtocolsRing, MSTP, IGMP Snooping, GMRP,VLAN,PVLAN, Telnet, HTTP, HTTPS, RMON,SNMPv1/v2/v3,LLDP,SNTP,DHCP server,SSH,SSL,ACL,FTP,ARP,QoS
    Interface
    Gigabit Ethernet port10/100/1000 Base-T(X) auto-adaptive RJ45, supports Power Over Ethernet
    RS232 Serial Console portRS232 in RJ45 connector with console cable
    Power port100-240VAC Power plug
    Switching Features
    Processing TypeStore & forward, wire speed switching
    Switching bandwidth50Gbps
    Packet forwarding speed37.2Mpps
    MAC Address8K
    Buffer Memory512KB
    Priority Queue4
    VLAN number4K
    VLAN ID1-4096
    Multicast groups256
    Software Features
    VLAN802.1Q,Vlan(4K), Port-based VLAN, Q-in-Q
    Storm SuppressionBroadcast, multicast, and unknown unicast storm suppression
    Flow controlIEEE802.3X negotiation, CAR function, rate limiting step 64K
    Multicast protocolIGMPv1/2/3 Snooping
    Port ManagementSupport port mirroring, port isolation, port trunking
    DHCP ManagementSupport DHCP Snooping, option 82
    QoS (Quality of Service)802.1p; Support port default priority tags, at least 4 different priority queues per port
    Security featuresMAC address filtering, dynamic or static MAC address learning, Loop detection and Port+ IP+MAC binding
    Traffic ManagementPort traffic monitoring and fault event alarming
    ManagementSNMP v1/v2/v3, CLI,WEB
    Management AccessSupport Console, Telnet
    System MaintenanceRMON,PDP Discovery Protocol(CDP compliant),AST
    File transferSupport Log output, configuration file backup and input


    Product Picture
    16 Gigabit PoE Ports High Power Poe Switch With IEEE802.3at Standard Ethernet Switch
    Topology
    16 Gigabit PoE Ports High Power Poe Switch With IEEE802.3at Standard Ethernet Switch


    LED Indicator for
    Power, Device running status, Ethernet port connection & running status
    POE Features
    POE Ports16* 10/100/1000Base-TX POE Ethernet ports
    Power supply modeSupply power while Power Device detected
    Bridging modeEndspan (V+ corresponds to 1,2; V- corresponds to 3,6 )
    AT ModeSupport IEEE802.3at confirmed PD, provide up to 30 Watts per port.
    Power
    Power Input100-240VAC to 455W inner POE power supply
    POE Power ConsumptionAT:30W(each port)
    ProtectionOverload current protection
    Mechanical
    Casing19” 1U metal casing
    Dimension(L*W*H)440*350*44.5mm
    InstallationRack mount
    Weight4.05Kg
    Environmental
    Operating Temperature-20℃~+60℃
    Storage Temperature-40℃~+85℃
    Relative Humidity5~95%,non-condensing
    Warranty
    Warranty Period2 years for Ethernet swtich


    Ordering information


    Available ModelsPort Interface

    1000Base FX
    SFP

    1000Base TX/FX Combo port1000Base T(X) POE30W
    MNB28G-16EGPT-M0016


    Package Checklist
    • Ethernet switch
    • Power wire unit
    • Hardware installation guide(printed)
    • Warranty Card

    Dimnsion
    16 Gigabit PoE Ports High Power Poe Switch With IEEE802.3at Standard Ethernet Switch

    Factory Office
    16 Gigabit PoE Ports High Power Poe Switch With IEEE802.3at Standard Ethernet Switch
