20 Ports POE Network Switch SFP Fiber Optic Inner 250 W AF Mode PoE Ethernet Switch

20 Ports POE Network Switch SFP Fiber Optic Inner 250 W AF Mode PoE Ethernet Switch

    • 20 Ports POE Network Switch SFP Fiber Optic Inner 250 W AF Mode PoE Ethernet Switch
    • 20 Ports POE Network Switch SFP Fiber Optic Inner 250 W AF Mode PoE Ethernet Switch
  • 20 Ports POE Network Switch SFP Fiber Optic Inner 250 W AF Mode PoE Ethernet Switch

    Product Details:

    Place of Origin: China
    Brand Name: Hengsion
    Certification: ISO/FCC/CE/RoSH
    Model Number: MNB28-16EP-4G-E

    Payment & Shipping Terms:

    Minimum Order Quantity: 10 sets
    Price: $20-2000/set
    Packaging Details: master carton
    Delivery Time: 5-15 work days
    Payment Terms: T/T, Western Union, L/C, D/A, D/P, MoneyGram
    Supply Ability: 3000sets/month
    Contact Now
    Detailed Product Description
    Protection: Overload Current Protection Packet Forwarding Speed: 11Mpps
    POE Ports: 16* 10/100Base-TX POE Ethernet Ports
    High Light:

    poe powered network switch

    ,

    outdoor poe switch

    MNB28-16EP-4G-E

    Unmanaged 16*1000BaseT(X) POE(15.4w)+2*1000Base-FX SFP+2*1000Base Combo Ethernet Switch



    Specification

    Technology
    Standards IEEE 802.3,802.3u,802.3x,802.3ab,802.3z; IEEE802.3 af.
    Interface
    Megabit Ethernet port 10/100 Base-T(X) auto-adaptive RJ45, supports Power Over Ethernet
    Gigabit Ethernet port 10/100/1000 Base-T(X) auto-adaptive RJ45
    Gigabit Fiber port 1000Base-X SFP port
    Power port 100-240VAC power plug
    Switching Features
    Processing Type Store & forward
    Switching bandwidth 19.6Gbps
    Packet forwarding speed 11Mpps
    MAC Address 8K
    Buffer Memory 384KB
    POE Features
    POE Ports 16* 10/100Base-TX POE Ethernet ports
    Power supply mode Supply power while Power Device detected
    Bridging mode Endspan (V+ corresponds to 1,2; V- corresponds to 3,6 )
    AF Mode Support IEEE802.3af confirmed PD, provide up to 15.4 Watts per port.



    Introduction



    HENGSION unmanaged MNB28-16EP-4G-E Ethernet switch provides 2*1000Base-X SFP fiber optic ports, 2*1000Base Combo ports, and 16*100BaseT(X) POE Ethernet ports. The POE Ethernet ports fully compliant with IEEE802.3af standards, provide up to 15.4 Watts per port to meet the user’s requirements of fast networking; MNB28-POE series’ wide operating temperature range and port surge protection design are ideal for application in large flow real-time outdoor environment, and are widely used for occasions including enterprise, intelligent building, cafe, community access or gathering etc., and for industries like finance, education and government etc.



    LED Indicator for
    Power, Ethernet port connection & running status, Fiber port connection & running status
    Power
    Power Input 100-240VAC to 250W inner POE power supply
    POE Power Consumption AF:15.4W(each port)
    Protection Overload current protection
    Mechanical
    Casing 19” 1U metal casing
    Dimension(L*W*H) 440*350*44.5mm
    Installation 1U rack mount
    Weight 3.8Kg
    Environmental
    Operating Temperature -20℃~+60℃
    Storage Temperature -40℃~+85℃
    Relative Humidity 5~95%,non-condensing
    Warranty
    Warranty Period 2 years for Ethernet swtich (power unit with 1year warranty)



    Dimension

    20 Ports POE Network Switch SFP Fiber Optic Inner 250 W AF Mode PoE Ethernet Switch



    Ordering information

    Available Models Port Interface

    1000Base FX

    SFP

    1000Base TX/FX Combo port 100Base T(X) POE15.4W
    MNB28-16EP-4G-E 2 2 16



    Optional Accessories (can be purchased separately)

    SFP-G-3155-J , 1Gbps SFP optical transceiver(T:1310nm/R:1550nm), single mode ,single fiber,20km

    SFP-G-5531-J , 1Gbps SFP optical transceiver(T:1550nm/R:1310nm), single mode ,single fiber,20km

    SFP-G-4-4955-J , 1Gbps SFP optical transceiver(T:1490nm/R:1550nm), single mode ,single fiber,40km

    SFP-G-4-5549-J , 1Gbps SFP optical transceiver(T:1550nm/R:1490nm), single mode ,single fiber,40km

    SFP-G-6-4955-J, 1Gbps SFP optical transceiver(T:1490nm/R:1550nm), single mode ,single fiber,60km

    SFP-G-6-5549-J , 1Gbps SFP optical transceiver(T:1550nm/R:1490nm), single mode ,single fiber,60km

    OM-SFP-G-D-31-J, 1.5Gbps SFP optical transceiver(1310nm), single mode ,dual fiber,20km



    Package Checklist



    • Ethernet switch

    • Power wire unit

    • Hardware installation guide(printed)

    • Warranty Card



    Topology

    20 Ports POE Network Switch SFP Fiber Optic Inner 250 W AF Mode PoE Ethernet Switch



    Workshop

    20 Ports POE Network Switch SFP Fiber Optic Inner 250 W AF Mode PoE Ethernet Switch
