25.6Gbps connecting network switches 48 port 10 / 100M ethernet and 4 port Gigabit fiber optic switch

25.6Gbps connecting network switches 48 port 10 / 100M ethernet and 4 port Gigabit fiber optic switch

25.6Gbps connecting network switches 48 port 10 / 100M ethernet and 4 port Gigabit fiber optic switch

Product Details:

Place of Origin: China
Brand Name: Hengsion
Certification: CE, FCC, ROHS
Model Number: ENB52-48E-4G

Payment & Shipping Terms:

Minimum Order Quantity: No less than 50 sets for one order.
Price: Negotiation
Packaging Details: Packing in individual boxes, then delivered with outer corrugated cartons.
Delivery Time: 3-15 working days after prepayment (depending on the stock)
Payment Terms: T/T at sight, LC, Western Union
Supply Ability: 3000 sets per month
Detailed Product Description
Industrial Design: No Fan, Low Power Consumption Design Full Loaded: Support Full-loaded Operating Temperature Range -20 To 70℃.
Gigabit Ethernet Port: 10/100/1000Base-TX Auto-adaptive RJ45 Full -load Consumption: 4.02A@5VDC(Max)
Installation: Rack Mount Warranty Period: 5 Years

ENB52-48E-4G

Unmanaged 48*100Base T(X) + 2*1000Base TX+ 2*1000Base SFP FX port Ethernet Switch



Introduction:



HENGSION unmanaged ENB52-48E-4G provides 2*10/100/1000 Base T(X) Ethernet port, 2*1000Base-X SFP fiber optic ports, and 48*100BaseT(X) fast Ethernet ports. No fan, low power consumption design; ENB28 series’ wide operating temperature range and port surge protection design are ideal for application in large flow real-time outdoor environment, and are widely used for occasions including enterprise, intelligent building, cafe, community access or gathering etc., and for industries like finance, education and government etc.



1. 48*100Base T(X) fast Ethernet ports & 2*10/100/1000 Base T(X) Ethernet port & 2 1000Base-X SFP fiber optic ports.

2. Support IEEE/802.3x full duplex flow control and Backpressure half duplex flow control.

3. No fan, low power consumption design.

4. Wire speed forwarding capability of all ports make sure of non-blocking message forwarding.

5. Automatic MDI/MDI-X crossover for plug-and-play

6. With power reverse polarity protection.

7. Support full-loaded operating temperature range -20 to 70℃.

8. 19” 1U Rack Mount installation















Specification:



Technology
Standards IEEE 802.3,802.3u,802.3x,IEEE802.3ab, IEEE802.3z
Interface
Megabit Ethernet port 10/100 Base-T(X) auto-adaptive RJ45
Gigabit Ethernet port 10/100/1000Base-TX auto-adaptive RJ45
Gigabit Fiber port 1000Base-X SFP port
Power port 100-240VAC Power plug
Switching Features
Processing Type Store & forward, wire speed switching
Switching bandwidth 25.6Gbps
Packet forwarding speed 14.6Mpps
MAC Address 8K
Buffer Memory 384KB
LED Indicator for
Power, Ethernet port connection & running status, Fiber port connection & running status
Power
Input Voltage Range 100-240VAC
Idle Consumption 1.95A@5VDC(Max)
Full -load Consumption 4.02A@5VDC(Max)
Connection Power plug
Protection Overload current protection; Reverse polarity protection
Mechanical
Casing 19” 1U metal casing
Dimension(L*W*H) 440*225*44mm
Installation Rack mount
Weight 2.7Kg
Environmental
Operating Temperature -20℃~+70℃
Storage Temperature -40℃~+85℃
Relative Humidity 5~95%,non-condensing
Warranty
Warranty Period 2 years



Ordering information:



Available Models Port Interface
1000Base FX SFP 10/100/1000Base T(X) 100Base F(X) 100Base T(X)
ENB52-48E-4G 2 2 0 48



Connection Topology:



25.6Gbps connecting network switches 48 port 10 / 100M ethernet and 4 port Gigabit fiber optic switch



Package Checklist:



• Ethernet switch

• Power adaptor

• Hardware installation guide(printed)

• Warranty Card



Dimension:



25.6Gbps connecting network switches 48 port 10 / 100M ethernet and 4 port Gigabit fiber optic switch
