AF standard 8 port Industrial POE Switch Store & forward Processing Type Unmanaged Ethernet Switch

AF standard 8 port Industrial POE Switch Store & forward Processing Type Unmanaged Ethernet Switch

    • AF standard 8 port Industrial POE Switch Store & forward Processing Type Unmanaged Ethernet Switch
    • AF standard 8 port Industrial POE Switch Store & forward Processing Type Unmanaged Ethernet Switch
  • AF standard 8 port Industrial POE Switch Store & forward Processing Type Unmanaged Ethernet Switch

    Product Details:

    Place of Origin: China
    Brand Name: Hengsion
    Certification: CE, FCC, ROHS
    Model Number: EIB09G-8EP-1F

    Payment & Shipping Terms:

    Minimum Order Quantity: No less than 50 sets for one order.
    Price: Negotiation
    Packaging Details: Packing in individual boxes, then delivered with outer corrugated cartons.
    Delivery Time: 3-15 working days after prepayment (depending on the stock)
    Payment Terms: T/T at sight, LC, Western Union
    Supply Ability: 3000 sets per month
    Contact Now
    Detailed Product Description
    POE Power Consumption: AF:15.4W(each Port) AF Mode: Support IEEE802.3af Confirmed PD, Provide Up To 15.4 Watts Per Port.
    Protection: Overload Current Protection Operating Temperature: -30℃~+70℃
    Storage Temperature: -45℃~+85℃ Relative Humidity: 5~95%,non-condensing
    High Light:

    poe enabled switch

    ,

    din rail poe switch

    EIB09G-8EP-1F

    Unmanaged 8*1000Base T(X) POE + 1*1000Base FX port Industrial Ethernet Switch


    Introduction
    HENGSION unmanaged EIB09G-8EP-1F industrial POE Ethernet switch provides 1 Gigabit fiber optic ports and 8 *10/100/1000 Base T(X) POE Ethernet ports. The POE Ethernet ports fully compliant with IEEE802.3af standards, provides 15.4Watts per port; No fan, low power consumption design; Din rail corrugated metal casing, meet IP40 protection grade; Dual redundant power input; Comply with CE, FCC and ROHS standards. Its wide operating temperature range and port surge protection design are ideal for application in large flow real-time outdoor environment, and are widely used in industrial automation control and surveillance occasions like campus, community, rail traffic, electric power control and so on.


    ◆ 8* 1000Base T(X) POE ports +1 Gigabit fiber optic ports

    ◆ POE Ethernet ports fully compliant with IEEE802.3af standard, provides 15.4 Watts per port.

    ◆ IEEE802.3/802.3u//802.3x, store and forward

    ◆ Wire speed forwarding capability of all ports make sure of non-blocking message forwarding.

    ◆ Automatic MDI/MDI-X crossover for plug-and-play

    ◆ Dual redundant power input, with overload protection and power reverse polarity protection.

    ◆ Support full-loaded operating temperature range -40 to 85℃.

    ◆ No fan, low power consumption design.

    ◆ Din rail corrugated metal casing, meet IP40 protection grade.

    ◆ Industrial Level-4 design.




    Specification

    Technology
    Standards IEEE 802.3, 802.3u, 802.3x, 802.3ab, 802.3z
    IEEE802.3 af;
    Interface
    Gigabit Ethernet port 10/100/1000 Base-T(X) auto-adaptive RJ45, supports Power Over Ethernet
    Gigabit Fiber port 1000Base-X fiber optic port (FC/SC/ST optional)
    Power supply 5.08 industrial terminal
    Switching Features
    Processing Type Store & forward
    Switching bandwidth 18Gbps
    Packet forwarding speed 13.39Mpps
    MAC Address 4K
    Buffer Memory 196KB
    Giant frame support 9720 bytes
    Multicast support 256
    LED Indicator for
    Power, running status, Ethernet port connection & running status, Fiber port connection & running status
    POE Features
    POE Ports 8* 10/100/1000Base-TX POE Ethernet ports
    Power supply mode Supply power while Power Device detected
    Bridging mode Endspan (V+ corresponds to 1,2; V- corresponds to 3,6 )
    AF Mode Support IEEE802.3af confirmed PD, provide up to 15.4 Watts per port.
    Power
    Input Voltage Range 90-264VAC to 48VDC
    POE Power Consumption AF:15.4W(each port)
    Protection Overload Current Protection
    Mechanical
    Casing Strengthened corrugated metal casing
    Protection grade IP40
    Dimension(L*W*H) 195*128.5*37mm
    Installation Din Rail
    Environmental
    Operating Temperature -30℃~+70℃
    Storage Temperature -45℃~+85℃
    Relative Humidity 5~95%,non-condensing
    Industry Approvals
    EMI FCC Part 15,CISPR(EN55022) class A





    EMS

    EN61000-4-2(ESD), Level 4
    EN61000-4-3(RS),Level 3
    EN61000-4-4(EFT),Level 4
    EN61000-4-5(Surge),Level 4
    EN61000-4-6(CS),Level 3
    EN61000-4-8,Level 5
    Shock IEC 60068-2-27
    Free Fall IEC 60068-2-32
    Vibration IEC 60068-2-6
    Warranty
    Warranty Period 3 years for Ethernet swtich (power unit with 1year warranty)


    Ordering Information

    Available Models Port Interface
    1000Base FX SFP 1000Base FX (ST/FC/SC) 10/100/1000Base T(X) 1000Base T(X) POE15.4W 1000Base T(X) POE 30W
    EIB09G-8EP-1F 0 1 0 8 0


    Package Checklist
    • Ethernet switch
    • Power wire unit
    • Hardware installation guide(printed)
    • Warranty Card
