15.4 Watts per port Industrial POE Switch 8 megabit TX POE with 1 megabit FX port Unmanaged Ethernet Switch

15.4 Watts per port Industrial POE Switch 8 megabit TX POE with 1 megabit FX port Unmanaged Ethernet Switch

    • 15.4 Watts per port Industrial POE Switch 8 megabit TX POE with 1 megabit FX port Unmanaged Ethernet Switch
    • 15.4 Watts per port Industrial POE Switch 8 megabit TX POE with 1 megabit FX port Unmanaged Ethernet Switch
  • 15.4 Watts per port Industrial POE Switch 8 megabit TX POE with 1 megabit FX port Unmanaged Ethernet Switch

    Product Details:

    Place of Origin: China
    Brand Name: Hengsion
    Certification: CE, FCC, ROHS
    Model Number: EII09-8EP-1F

    Payment & Shipping Terms:

    Minimum Order Quantity: No less than 50 sets for one order.
    Price: Negotiation
    Packaging Details: Packing in individual boxes, then delivered with outer corrugated cartons.
    Delivery Time: 3-15 working days after prepayment (depending on the stock)
    Payment Terms: T/T at sight, LC, Western Union
    Supply Ability: 3000 sets per month
    Contact Now
    Detailed Product Description
    POE Ports: 8* 10/100Base-TX POE Ethernet Ports EMI: FCC Part 15,CISPR(EN55022) Class A
    Installation: Din Rail Power Supply Mode: Supply Power While Power Device Detected
    Weight: 1.3KG Switching Bandwidth: 1.6Gbps

    EII09-8EP-1F

    Unmanaged 8*100Base T(X) POE + 1*100Base FX port Industrial Ethernet Switch


    Introduction

    HENGSION unmanaged EII09-8EP-1F industrial POE Ethernet switch provides 1*100Base-FX fiber optic ports (FC/SC/ST optional) and 8 *10/100Base T(X) POE Ethernet ports. The POE Ethernet ports fully compliant with IEEE802.3af standards, provides 15.4Watts per port; No fan, low power consumption design; Din rail corrugated metal casing, meet IP40 protection grade; Dual redundant power input; Comply with CE, FCC and ROHS standards. Its wide operating temperature range and port surge protection design are ideal for application in large flow real-time outdoor environment, and are widely used in industrial automation control and surveillance occasions like campus, community, rail traffic, electric power control and so on.



    ▲ 8* 100Base T(X) POE ports + 1*100Base FX fiber optic ports

    ▲ POE Ethernet ports fully compliant with IEEE802.3af standard, provides 15.4 Watts per port.

    ▲ IEEE802.3/802.3u//802.3x, store and forward

    ▲ Wire speed forwarding capability of all ports make sure of non-blocking message forwarding.

    ▲ Automatic MDI/MDI-X crossover for plug-and-play

    ▲ Redundant power input, with overload protection and power reverse polarity protection.

    ▲ Support full-loaded operating temperature range -30 to 70℃.

    ▲ No fan, low power consumption design.

    ▲ Din rail corrugated metal casing, meet IP40 protection grade.

    ▲ Industrial Level-4 design.




    Specification

    Technology
    Standards IEEE 802.3, 802.3u, 802.3x, 802.3ab, 802.3z
    IEEE802.3 af;
    Interface
    Megabit Ethernet port 10/100 Base-T(X) auto-adaptive RJ45, supports Power Over Ethernet
    Megabit Fiber port 100Base-X fiber port(FC/SC/ST optional)
    Power supply 5.08 industrial terminal
    Switching Features
    Processing Type Store & forward
    Switching bandwidth 1.6Gbps
    Packet forwarding speed 1.2Mpps
    MAC Address 1K
    Buffer Memory 512Kb
    LED Indicator for
    Power, running status, Ethernet port connection & running status, Fiber port connection & running status
    POE Features
    POE Ports 8* 10/100Base-TX POE Ethernet ports
    Power supply mode Supply power while Power Device detected
    Bridging mode Endspan (V+ corresponds to 1,2; V- corresponds to 3,6 )
    AF Mode Support IEEE802.3af confirmed PD, provide up to 15.4 Watts per port.
    Power
    Input Voltage Range 90-264VAC to 48VDC
    POE Power Consumption AF:15.4W(each port)
    Protection Overload Current Protection
    Mechanical
    Casing Strengthened corrugated metal casing
    Protection grade IP40
    Dimension(L*W*H) 280*152*43.5mm
    Installation Din Rail
    Weight 1.3KG
    Environmental
    Operating Temperature -20℃~+70℃
    Storage Temperature -40℃~+85℃
    Relative Humidity 5~95%,non-condensing
    Industry Approvals
    EMI FCC Part 15,CISPR(EN55022) class A





    EMS

    EN61000-4-2(ESD), Level 4
    EN61000-4-3(RS),Level 3
    EN61000-4-4(EFT),Level 4
    EN61000-4-5(Surge),Level 4
    EN61000-4-6(CS),Level 3
    EN61000-4-8,Level 5
    Shock IEC 60068-2-27
    Free Fall IEC 60068-2-32
    Vibration IEC 60068-2-6
    Warranty
    Warranty Period 3 years for Ethernet swtich (power unit with 1year warranty)

    Ordering Information

    Available Models Port Interface
    1000Base FX FC/SC/ST 10/100/1000Base T(X) 100Base T(X) 100Base T(X) POE15.4W 100Base T(X) POE 30W
    EII09-8EP-1F 1 0 0 8 0


    Package Checklist
    • Ethernet switch
    • Power wire unit
    • Hardware installation guide(printed)
    • Warranty Card
