64 channel video Fiber optic transceiver Hot swap function cctv fiber transceiver

64 channel video Fiber optic transceiver Hot swap function cctv fiber transceiver

64 channel video Fiber optic transceiver Hot swap function cctv fiber transceiver

Product Details:

Place of Origin: China
Brand Name: Hengsion
Certification: CE, FCC, ROHS
Model Number: DDT-E-T/R640SF

Payment & Shipping Terms:

Minimum Order Quantity: No less than 20 sets for one order.
Price: Negotiation
Packaging Details: Packing in individual boxes, then delivered with outer corrugated cartons.
Delivery Time: 3-15 working days after prepayment (depending on the stock)
Payment Terms: T/T at sight, LC, Western Union
Supply Ability: 3000 sets per month
Detailed Product Description
Fiber Connector: FC/ SC/ ST/ LC Optional Number Of Channels: 64-Channel Video
Video Input/Output Impedance: BNC 75Ω Video Standard: PAL/NTSC/SECAM
Working Temperature: -30℃~ +70℃ Power Input: AC 100~240V,AC/DC12~48V Optional
Size(Standalone): 440 ×220 ×242mm Wavelength: Single-mode 1310nm/1550Nm, Multimode 850nm/1310nm

Non-Condensing Analogue Video Optical Transceivers



64V↑



64-Channel Video Fiber Optic Transceiver





Standard Products:

Module No.:

Transmitter: DDT-D-T640SSFC

Receiver: DDT-D-R640SSFC

Standard Products:

Single mode, single fiber, 20 km, FC

Multi mode, single fiber, 2 km, FC







Introduction



The video optical transceivers are typically used in applications with fixed or PTZ cameras. Plug and Play design ensures the ease of installation and operation. Electronic and optical adjustments are never required. LED indicators are provided for instantly monitoring system status. Devices are available for either standalone or rack-mount installation, which is suitable for different working environments.



It is now widely used in security monitoring and control system, highway, Traffic Control Photographic System, automation and intelligent residence etc.





The function of network management is optional, and the running status of the system can be monitored by inserting just one network-managing card.





HENGSION Digital Non-Condensing Video Optical Transceivers can simultaneously transmit 1-128 channels of 8 bit/10 bit composite video signalsreverse or bidirectional data(Rs485/232/422)unidirectional or bidirectional audioEthernetTelephone, dry contactE1 signals over one multimode or single-mode optical fiber……









Features



● Directly compatible with NTSC,PAL,SECAM CCTV camera systems and support RS232, RS485, RS422, and Manchester code



● 8 / 10 bit digitally encoded and non-compression video transmission



● Available for monitoring the running status of the system with the LEDs indicating parameters status of power, link and video



● Transmission distance can reach 120km without relay in single mode



● Industrial-level design with SMT techniques



● Special ASIC design & Hot-swap function



● Support no-damage regenerative trunk of video



● Without electro-magnetic RF(radio frequency) and terrestrial current disturbances. Interfaces are under thunder and lightning protection



● Stand-alone type or card-type installed in 19"2U, 4U or 5.5U rack-mount chassis



● Network management functions are optional



● Support customization and OEM








Benchmarks:

Fiber Interface
Connector FC/ SC/ ST/ LC optional
Wavelength single-mode 1310nm/1550Nm, multimode 850nm/1310nm
Transmission power ≥-9dBm
Receiving sensitivity >-34dBm(bit error rate<10 -12)
Transmission distance single-mode max 120km, multi-mode max 2km
Video
Number of Channels 64-Channel Video
Video Input/Output Impedance BNC 75Ω
Video standard PAL/NTSC/SECAM
Quantization 8/10 bit
Video Input/Output Voltage 1.0VPP (Typical value)
Video Input/Output Voltage 1.5VPP (Maximum Value)
Band width per channel ≥6.5 MHZ
Differential Gain DG < 1% (Typical value)
Differential phase DP < 1°
SNR(Signal to Noise Ratio) ≥67dB /71dB(Weighted Value)
Electrical & Mechanical
Power Input AC 100~240V,AC/DC12~48V optional
Direct-current Output DC 5V@16A
Power Protection Overvoltage Protection, Over-current Protection
Power Consumption <100W
Size(Standalone) 440 ×220 ×242mm
Environment
Working Temperature -30℃~ +70℃
Working Humidity 0~95% (Non-condensing)
Reliability
Mean Time Between Failures > 100,000 hours
