Gigabit POE Switch 802.1x authentication power over ethernet switch 16 port

Gigabit POE Switch 802.1x authentication power over ethernet switch 16 port

    • Gigabit POE Switch 802.1x authentication power over ethernet switch 16 port
    • Gigabit POE Switch 802.1x authentication power over ethernet switch 16 port
  • Gigabit POE Switch 802.1x authentication power over ethernet switch 16 port

    Product Details:

    Place of Origin: China
    Brand Name: Hengsion
    Certification: CE, FCC, ROHS
    Model Number: MNB24G-16EP-4G

    Payment & Shipping Terms:

    Minimum Order Quantity: No less than 50 sets for one order.
    Price: Negotiation
    Packaging Details: Packing in individual boxes, then delivered with outer corrugated cartons.
    Delivery Time: 3-15 working days after prepayment (depending on the stock)
    Payment Terms: T/T at sight, LC, Western Union
    Supply Ability: 3000 sets per month
    Detailed Product Description
    Weight: 4.3Kg Casing: 19” 1U Metal Casing
    QoS (Quality Of Service): 802.1p; Support Port Default Priority Tags, At Least 4 Different Priority Queues Per Port Port Management: Support Port Mirroring, Port Isolation, Port Trunking
    Flow Control: IEEE802.3X Negotiation, CAR Function, Rate Limiting Step 64K VLAN ID: 1-4096
    Gigabit Ethernet Port: 10/100/1000Base-TX Auto-adaptive RJ45

    MNB24G-16EP-4G
    Managed 16*1000Base T(X) POE +4*1000 Base-FX SFP port Ethernet Switch

    Introduction

    HENGSION managed MNB24G-16EP-4G Ethernet switch provides 4*1000Base Combo ports, and 16*1000BaseT(X) POE Ethernet ports.
    The POE Ethernet ports fully compliant with IEEE802.3af standards, provide up to 15.4 Watts per port to meet the user’s requirements of fast networking;
    Support Ethernet redundant Ring protocol( recovery time<20ms), with complete security and QoS policies;
    Support VLAN division, port mirroring, and port rate limiting;
    Support broadcast storm suppression, flow control, and centralized management and configuration by WEB,CLI,SNMP;

    ▼ 16*1000Base T(X) POE Ethernet ports & 4 Gigabit Combo port.
    ▼ POE Ethernet ports fully compliant with IEEE802.3af standard provide up to 15.4 Watts per port.
    ▼ Support Ethernet redundant Ring protocol( recovery time≤20ms)
    ▼ Wire speed forwarding capability of all ports make sure of non-blocking message forwarding.
    ▼ Support 802.1x authentication, VLAN, and broadcast storm suppression.
    ▼ Loop detection and Port+ IP+MAC binding.
    ▼ Port traffic monitoring and fault event alarming
    ▼ Support WEB visual interface, support SNMP management.
    ▼ Automatic MDI/cfor plug-and-play
    ▼ Overload protection and power reverse polarity protection.
    ▼ Full-loaded operating temperature range -20 to 70℃.
    ▼ No fan, low power consumption design.
    ▼ 19” 1U Rack Mount installation


    Specification

    Technology
    Standards

    IEEE 802.3,802.3u,802.3x, 802.3ab, 802.3z; IEEE802.1Q,802.1p,802.1D,802.1w,802.1s,802.1X,802.1ab
    IEEE802.3af

    ProtocolsRing, MSTP, IGMP Snooping, GMRP,VLAN,PVLAN, Telnet, HTTP, HTTPS, RMON,SNMPv1/v2/v3,LLDP,SNTP,DHCP server,SSH,SSL,ACL,FTP,ARP,QoS
    Interface
    Gigabit Ethernet port10/100/1000 Base-T(X) auto-adaptive RJ45, supports Power Over Ethernet
    Gigabit Ethernet port10/100/1000Base-TX auto-adaptive RJ45
    Gigabit Fiber port1000Base-X SFP port
    RS232 Serial Console portRS232 in RJ45 connector with console cable
    Power port90-264VAC Power plug
    Switching Features
    Processing TypeStore & forward, wire speed switching
    Switching bandwidth50Gbps
    Packet forwarding speed37.2Mpps
    MAC Address8K
    Buffer Memory512KB
    Priority Queue4
    VLAN number4K
    VLAN ID1-4096
    Multicast groups256
    Software Features
    VLAN802.1Q,Vlan(4K), Port-based VLAN, Q-in-Q
    Storm SuppressionBroadcast, multicast, and unknown unicast storm suppression
    Flow controlIEEE802.3X negotiation, CAR function, rate limiting step 64K
    Multicast protocolIGMPv1/2/3 Snooping
    Port ManagementSupport port mirroring, port isolation, port trunking
    DHCP ManagementSupport DHCP Snooping, option 82
    QoS (Quality of Service)802.1p; Support port default priority tags, at least 4 different priority queues per port
    Security featuresMAC address filtering, dynamic or static MAC address learning, Loop detection and Port+ IP+MAC binding
    Traffic ManagementPort traffic monitoring and fault event alarming
    ManagementSNMP v1/v2/v3, CLI,WEB
    Management AccessSupport Console, Telnet
    System MaintenanceRMON,PDP Discovery Protocol(CDP compliant),AST
    File transferSupport Log output, configuration file backup and input
    LED Indicator for
    Power, Device running status, Ethernet port connection & running status, Fiber port connection & running status
    POE Features
    POE Ports16* 10/100/1000Base-TX POE Ethernet ports
    Power supply modeSupply power while Power Device detected
    Bridging modeEndspan (V+ corresponds to 1,2; V- corresponds to 3,6 )
    AF ModeSupport IEEE802.3af confirmed PD, provide up to 15.4 Watts per port.
    Power
    Power Input90-264VAC
    POE Power ConsumptionAF:15.4W(each port)
    ProtectionOverload current protection
    Mechanical
    Casing19” 1U metal casing
    Dimension(L*W*H)440*350*44mm
    Installation1U Rack mount
    Weight4.3Kg
    Environmental
    Operating Temperature-20℃~+70℃
    Storage Temperature-40℃~+85℃
    Relative Humidity5~95%,non-condensing
    Warranty
    Warranty Period2 years for Ethernet swtich (power unit with 1year warranty)


    Ordering Information

    Available ModelsPort Interface
    1000Base FX SFP1000Base TX port100Base T(X) POE15.4W
    Combo port
    MNB24G-16EP-4G

    4
    2

    16


    Package Checklist
    • Ethernet switch
    • Power wire unit
    • Hardware installation guide(printed)
    • Warranty Card

    Dimension
