| Place of Origin: | China |
| Brand Name: | Hengsion |
| Certification: | CE, FCC, ROHS |
| Model Number: | ENB24G-24EP |
| Minimum Order Quantity: | No less than 50 sets for one order. |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Packing in individual boxes, then delivered with outer corrugated cartons. |
| Delivery Time: | 3-15 working days after prepayment (depending on the stock) |
| Payment Terms: | T/T at sight, LC, Western Union |
| Supply Ability: | 3000 sets per month |
| Warranty Period: | 2 Years For Ethernet Swtich (power Unit With 1year Warranty) | Relative Humidity: | 5～95%,non-condensing |
|---|---|---|---|
| Storage Temperature: | -40℃～+85℃ | Installation: | 1U Rack Mount |
| AF Mode: | Support IEEE802.3af Confirmed PD, Provide Up To 15.4 Watts Per Port. | Bridging Mode: | Endspan (V+ Corresponds To 1,2; V- Corresponds To 3,6 ) |
| POE Ports: | 24*10/100/1000Base-TX POE Ethernet Ports | ||
| High Light: | poe desktop switch,gigabit ethernet poe switch |
||
ENB24G-24EP
Unmanaged 24*1000Base T(X) POE port Ethernet Switch
Introduction
HENGSION unmanaged ENB24G-24EP Ethernet switch provides 24*10/100/1000M POE Ethernet ports. The POE Ethernet ports fully compliant with IEEE802.3af standards, provide up to 15.4 Watts per port to meet the user’s requirements of fast networking; ENB24G POE series’ wide operating temperature range and port surge protection design are ideal for application in large flow real-time outdoor environment, and are widely used for occasions including enterprise, intelligent building, cafe, community access or gathering etc., and for industries like finance, education and government etc.
▶ 24*1000Base T(X) POE Ethernet ports.
▶ POE Ethernet ports fully compliant with IEEE802.3af standard provide up to 15.4 Watts per port.
▶ Support IEEE/802.3x full duplex flow control and Backpressure half duplex flow control.
▶ Wire speed forwarding capability of all ports make sure of non-blocking message forwarding.
▶ Automatic MDI/MDI-X crossover for plug-and-play
▶ With power overload current protection.
▶ No fan, low power consumption design.
▶ Support full-loaded operating temperature range -20 to 70℃.
▶ 19” 1U Rack Mount installation
Specification
| Technology | |
| Standards | IEEE 802.3,802.3u,802.3x,802.3ab,802.3z; IEEE802.3 af. |
| Interface | |
| Gigabit Ethernet port | 10/100 /1000 Base-T(X) auto-adaptive RJ45, supports Power Over Ethernet |
| Power port | 100-240VAC power plug |
| Switching Features | |
| Processing Type | Store & forward |
| Switching bandwidth | 50Gbps |
| Packet forwarding speed | 37.2 Mpps |
| MAC Address | 8K |
| Buffer Memory | 512KB |
| POE Features | |
| POE Ports | 24*10/100/1000Base-TX POE Ethernet ports |
| Power supply mode | Supply power while Power Device detected |
| Bridging mode | Endspan (V+ corresponds to 1,2; V- corresponds to 3,6 ) |
| AF Mode | Support IEEE802.3af confirmed PD, provide up to 15.4 Watts per port. |
| LED Indicator for | |
| Power, Ethernet port connection & running status | |
| Power | |
| Power Input | 100-240VAC |
| POE Power Consumption | AF:15.4W(each port) |
| Protection | Overload current protection |
| Mechanical | |
| Casing | 19” 1U metal casing |
| Dimension(L*W*H) | 440*350*44mm |
| Installation | 1U rack mount |
| Weight | 2.85Kg |
| Environmental | |
| Operating Temperature | -20℃～+70℃ |
| Storage Temperature | -40℃～+85℃ |
| Relative Humidity | 5～95%,non-condensing |
| Warranty | |
| Warranty Period | 2 years for Ethernet swtich (power unit with 1year warranty) |
Ordering Information
| Available Models | Port Interface | ||
| 1000Base FX SFP | 1000Base TX port | 100Base T(X) POE15.4W | |
| Combo port | |||
| ENB24G-24EP |
0 2 |
24 | |
Package Checklist
• Ethernet switch
• Power wire unit
• Hardware installation guide(printed)
• Warranty Card
Dimension
